| Bandwidth |
| Data transfer rate (max) |
5000 Mbit/s |
| Full duplex |
Y |
| Maximum data transfer rate |
5000 Mbit/s |
| Networking |
| Networking standards |
IEEE 802.3,IEEE 802.3ab,IEEE 802.3az,IEEE 802.3u |
| Chipset |
Genesys Logic - GL3522, ASIX - AX88179 |
| Ethernet LAN |
Y |
| Cabling technology |
10/100/1000BaseT(X) |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Flow control support |
Y |
| Jumbo frames support |
Y |
| Jumbo frames |
4000 |
| Maximum data transfer rate |
5000 Mbit/s |
| Full duplex |
Y |
| Wake-on-LAN ready |
Y |
| Auto MDIX IEEE |
Y |
| Auto-negotiation |
Y |
| System requirements |
| Windows operating systems supported |
Windows 10 Education,Windows 10 Education x64,Windows 10 Enterprise,Windows 10 Enterprise x64,Windows 10 Home,Windows 10 Home x64,Windows 10 IOT Core,Windows 10 Pro,Windows 10 Pro x64,Windows 10 x64,Windows 7,Windows 7 Enterprise,Windows 7 Enterprise x64, |
| Mac operating systems supported |
Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks |
| Linux operating systems supported |
Y |
| Other operating systems supported |
Chrome |
| Server operating systems supported |
Windows Server 2003,Windows Server 2008 R2,Windows Server 2012,Windows Server 2012 R2,Windows Server 2016,Windows Server 2019 |
| Weight & dimensions |
| Width |
43 mm |
| Depth |
87 mm |
| Height |
14 mm |
| Weight |
62 g |
| Package width |
150 mm |
| Package depth |
215 mm |
| Package height |
52 mm |
| Package weight |
366 g |
| Ports & interfaces |
| Connectivity technology |
Wired |
| Internal |
N |
| Host interface |
USB |
| Interface |
Ethernet |
| Ethernet LAN (RJ-45) ports |
1 |
| USB version |
3.2 Gen 1 (3.1 Gen 1) |
| USB 3.0 (3.1 Gen 1) Type-A hub ports quantity |
3 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A hub ports quantity |
3 |
| Operational conditions |
| Operating temperature (T-T) |
0 - 50 °C |
| Storage temperature (T-T) |
-10 - 75 °C |
| Operating relative humidity (H-H) |
0 - 85% |
| Power |
| Input voltage |
100-240 V |
| Input current |
0.3 A |
| Output voltage |
5 V |
| Output current |
2 A |
| Power consumption (typical) |
10 W |
| Plug type |
Type H (IL) |
| Power plug type |
Type H (IL) |
| AC input voltage |
100-240 V |
| Certificates |
| Certification |
CE, FCC |
| RoHS compliance |
Y |
| Packaging content |
| Manual |
Y |
| Drivers included |
Y |
| AC adapter included |
Y |
| Included power plug types |
AU,EU,NA,UK |
| Other features |
| Cable length |
0.148 m |
| Chipset |
Genesys Logic - GL3522, ASIX - AX88179 |
| USB data transfer rates |
12,480,5000 Mbit/s |
| Power plug type |
Type H |
| Housing material |
Aluminium |
| AC input voltage |
100-240 V |
| Flow control support |
Y |
| Jumbo frames |
4000 |
| Design |
| Colour of product |
Black |
| Housing material |
Aluminium |
| LED indicators |
Activity, Link |
| Product colour |
Black |
| Internal |
N |
| RoHS compliance |
Y |
| Certification |
CE, FCC |
| Chipset |
Genesys Logic - GL3522, ASIX - AX88179 |
| Performance |
| Wake-on-LAN ready |
Y |
| Auto MDIX IEEE |
Y |
| Cable length |
0.148 m |
| Auto-negotiation |
Y |
| USB data transfer rates |
12,480,5000 Mbit/s |
| Packaging data |
| AC adapter included |
Y |
| Manual |
Y |
| Drivers included |
Y |
| Included power plug types |
AU,EU,NA,UK |
| Package width |
217 mm |
| Package depth |
152 mm |
| Package height |
53 mm |
| Package weight |
374 g |
| Technical details |
| Sustainability certificates |
RoHS |
| Packaging content |
| Manual |
Y |
| Sustainability |
| Sustainability certificates |
RoHS |
