| Weight & dimensions |
| Width |
45 mm |
| Depth |
90 mm |
| Height |
15 mm |
| Weight |
60 g |
| USB cable length |
0.063 m |
| Performance |
| USB version |
3.2 Gen 1 (3.1 Gen 1) |
| DVI output |
No |
| HDMI output |
No |
| DisplayPort output |
Yes |
| Number of displays supported |
1 |
| USB connector type |
USB Type-A |
| USB connector gender |
Male |
| Internal memory |
1024 MB |
| Maximum resolution |
3840 x 2160 pixels |
| Refresh rate at maximum resolution |
30 Hz |
| Supported graphics resolutions |
1280 x 800, 1366 x 768, 2048 x 1152, 3840 x 2160, 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 768 (WXGA), 1400 x 1050 (SXGA+), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 640 x 480 (VGA), 800 |
| Supported video modes |
480p, 720p, 1080p, 2160p |
| Audio output channels |
2.0 channels |
| Chipset |
DisplayLink - DL-5500 |
| USB pass-through |
No |
| Certification |
CE, FCC, TAA, DisplayLink, REACH |
| Packaging content |
| Manual |
Yes |
| Software CD |
Yes |
| System requirements |
| Windows operating systems supported |
Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 x64, Window |
| Mac compatibility |
Yes |
| Mac operating systems supported |
Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X |
| Linux operating systems supported |
Ubuntu 18.04 LTS, Ubuntu 20.04 LTS, Ubuntu 22.04 |
| Other operating systems supported |
ChromeOS |
| Minimum processor family |
Core i5 |
| Minimum processor speed |
2.4 GHz |
| Minimum RAM |
4 TB |
| Design |
| Product colour |
Black |
| Housing material |
Plastic |
| Integrated USB cable |
Yes |
| Technical details |
| Compliance certificates |
RoHS |
| Operational conditions |
| Operating temperature (T-T) |
10 - 40 °C |
| Storage temperature (T-T) |
-10 - 80 °C |
| Operating relative humidity (H-H) |
0 - 85% |
| Logistics data |
| Products per master (outer) case |
20 pc(s) |
| Master (outer) case width |
240 mm |
| Master (outer) case length |
410 mm |
| Master (outer) case height |
319 mm |
| Harmonized System (HS) code |
84733020 |
| Packaging data |
| Package type |
Box |
| Package width |
144 mm |
| Package depth |
211 mm |
| Package height |
38 mm |
| Package weight |
204 g |
