| Weight & dimensions |
| Width |
58.6 mm |
| Depth |
196 mm |
| Height |
24 mm |
| Weight |
340 g |
| Ports & interfaces |
| Connectivity technology |
Wired |
| Host interface |
Thunderbolt 3 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
2 |
| HDMI ports quantity |
1 |
| Microphone in |
N |
| VGA (D-Sub) ports quantity |
1 |
| DisplayPorts quantity |
2 |
| DC-in jack |
Y |
| USB Power Delivery |
Y |
| USB Power Delivery up to |
85 W |
| Power |
| Power source type |
AC |
| AC input voltage |
100 - 240 V |
| Input current |
1.8 A |
| Power supply |
85 W |
| Power supply type |
External |
| Output voltage |
19 V |
| Output current |
6.32 A |
| Power consumption (typical) |
120 W |
| Power plug type |
Type N |
| Compatible power plug types |
EU,UK |
| Packaging content |
| Cables included |
AC, Thunderbolt |
| AC adapter included |
Y |
| Manual |
Y |
| Other features |
| Cable length |
0.5 m |
| Chipset |
Intel - Alpine Ridge JHL6540, Intel - WGI210AT, ASMedia - ASM1042A, Parade - PS176, Chrontel - CH7517 |
| Operational conditions |
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-20 - 70 °C |
| Operating relative humidity (H-H) |
20 - 80% |
| Networking |
| Ethernet LAN |
Y |
| Ethernet LAN (RJ-45) ports |
1 |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Networking standards |
IEEE 802.3,IEEE 802.3ab,IEEE 802.3u |
| Auto MDI/MDI-X |
Y |
| Full duplex |
Y |
| 10G support |
N |
| Performance |
| Product colour |
Grey |
| Card reader integrated |
N |
| Maximum digital resolution |
4096 x 2160 pixels |
| UASP support |
Y |
| Housing material |
Aluminium |
| RoHS compliance |
Y |
| Certification |
CE, FCC, REACH |
| HD type |
4K Ultra HD |
| Technical details |
| Sustainability certificates |
RoHS |
| Software |
| Windows operating systems supported |
Windows 10,Windows 10 Education,Windows 10 Education x64,Windows 10 Enterprise,Windows 10 Enterprise x64,Windows 10 Home,Windows 10 Home x64,Windows 10 IOT Core,Windows 10 Pro,Windows 10 Pro x64,Windows 7,Windows 7 Enterprise,Windows 7 Enterprise x64,Wind |
| Mac compatibility |
Y |
| Mac operating systems supported |
Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina |
| Packaging data |
| Package width |
187 mm |
| Package depth |
254 mm |
| Package height |
65 mm |
| Package weight |
1.3 kg |
| Logistics data |
| Quantity per master (outer) case |
20 pc(s) |
| Master (outer) case width |
39 cm |
| Master (outer) case length |
67.6 cm |
| Master (outer) case height |
28 cm |
| Products per master (outer) case |
20 pc(s) |
| Sustainability |
| Sustainability certificates |
RoHS |
