| Weight & dimensions |
| Width |
86.2 mm |
| Depth |
216 mm |
| Height |
31 mm |
| Weight |
291 g |
| Ports & interfaces |
| Connectivity technology |
Wired |
| Host interface |
USB 3.2 Gen 1 (3.1 Gen 1) Type-B |
| USB 2.0 ports quantity |
0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
6 |
| HDMI ports quantity |
1 |
| Headphone outputs |
1 |
| DVI-I ports quantity |
1 |
| Combo headphone/mic port |
Yes |
| Headphone connectivity |
3.5 mm |
| DC-in jack |
Yes |
| Power |
| Power source type |
AC |
| AC input voltage |
100 - 240 V |
| Input current |
1 A |
| Output voltage |
20 V |
| Output current |
2 A |
| Power consumption (typical) |
40 W |
| Power plug type |
Type N |
| Compatible power plug types |
AU, EU, JP, UK, US |
| Packaging content |
| Cables included |
USB |
| AC adapter included |
Yes |
| Quick start guide |
Yes |
| Other features |
| Cable length |
1 m |
| Chipset |
DisplayLink - DL-3900, VIA/VLI - VL813 |
| Operational conditions |
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-10 - 70 °C |
| Operating relative humidity (H-H) |
10 - 90% |
| Networking |
| Ethernet LAN |
Yes |
| Ethernet LAN (RJ-45) ports |
1 |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Wake-on-LAN ready |
Yes |
| Networking standards |
IEEE 802.3, IEEE 802.3ab, IEEE 802.3u |
| Auto MDI/MDI-X |
Yes |
| Full duplex |
Yes |
| Performance |
| Product colour |
Black, Silver |
| Card reader integrated |
No |
| Data transfer rate |
5 Gbit/s |
| Maximum digital resolution |
2048 x 1152 pixels |
| Number of displays supported |
2 |
| On/off switch |
Yes |
| LED indicators |
Power |
| UASP support |
Yes |
| Housing material |
Plastic |
| Brand compatibility |
Any brand |
| Certification |
CE, FCC, DisplayLink, REACH |
| Technical details |
| Compliance certificates |
RoHS |
| Software |
| Windows operating systems supported |
Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 7, Windows 7 Enterprise, W |
| Mac operating systems supported |
Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 13.0 Ventura |
| Packaging data |
| Package width |
140 mm |
| Package depth |
307 mm |
| Package height |
60 mm |
| Package weight |
800 g |
| Logistics data |
| Products per master (outer) case |
10 pc(s) |
| Master (outer) case width |
315 mm |
| Master (outer) case length |
325 mm |
| Master (outer) case height |
295 mm |
| Harmonized System (HS) code |
84733020 |
