| Weight & dimensions |
| Width |
70 mm |
| Depth |
122 mm |
| Height |
14 mm |
| Weight |
129 g |
| Ports & interfaces |
| Connectivity technology |
Wired |
| Host interface |
USB 3.2 Gen 1 (3.1 Gen 1) Type-C |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
3 |
| HDMI ports quantity |
1 |
| Microphone in |
N |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity |
1 |
| VGA (D-Sub) ports quantity |
1 |
| Power |
| Power source type |
USB |
| Packaging content |
| Manual |
Y |
| Other features |
| Cable length |
0.118 m |
| Chipset |
VIA/VLI - VL102, VIA/VLI - VL817, Parade - PS8338B, Parade - PS176, Analogix - ANX9833, ALCOR MICRO - AU84612, Realtek - RTL8153 |
| Operational conditions |
| Operating temperature (T-T) |
0 - 45 °C |
| Storage temperature (T-T) |
-10 - 70 °C |
| Operating relative humidity (H-H) |
10 - 90% |
| Networking |
| Ethernet LAN |
Y |
| Ethernet LAN (RJ-45) ports |
1 |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Networking standards |
IEEE 802.3,IEEE 802.3ab,IEEE 802.3u |
| Auto MDI/MDI-X |
Y |
| Full duplex |
Y |
| 10G support |
N |
| Performance |
| Product colour |
Black |
| Card reader integrated |
Y |
| Compatible memory cards |
MMC, MicroSD (TransFlash), SD |
| Data transfer rate |
5 Gbit/s |
| Maximum digital resolution |
3840 x 2160 pixels |
| UASP support |
Y |
| Housing material |
Plastic |
| RoHS compliance |
Y |
| Certification |
CE, FCC, REACH |
| Technical details |
| Sustainability certificates |
RoHS |
| Software |
| Windows operating systems supported |
Windows 10,Windows 10 Education,Windows 10 Education x64,Windows 10 Enterprise,Windows 10 Enterprise x64,Windows 10 Home,Windows 10 Home x64,Windows 10 IOT Core,Windows 10 Pro,Windows 10 Pro x64,Windows 10 x64,Windows 7,Windows 7 Enterprise,Windows 7 Ente |
| Mac compatibility |
Y |
| Mac operating systems supported |
Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina |
| Other operating systems supported |
Chrome |
| Packaging data |
| Package width |
179 mm |
| Package depth |
142 mm |
| Package height |
30 mm |
| Package weight |
137 g |
| Quantity per pack |
1 pc(s) |
| Logistics data |
| Quantity per master (outer) case |
60 pc(s) |
| Master (outer) case width |
33 cm |
| Master (outer) case length |
53 cm |
| Master (outer) case height |
31 cm |
| Products per master (outer) case |
60 pc(s) |
| Sustainability |
| Sustainability certificates |
RoHS |
