| Networking |
| Maximum data transfer rate |
150 Mbit/s |
| Networking standards |
IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Wi-Fi |
Yes |
| Wi-Fi band |
Single-band (2.4 GHz) |
| Top Wi-Fi standard |
Wi-Fi 4 (802.11n) |
| Wi-Fi standards |
802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| WLAN data transfer rates supported |
11,54,150 Mbit/s |
| Security algorithms |
128-bit WEP, 64-bit WEP, TKIP, WPA, WPA-AES, WPA2 |
| Full duplex |
Yes |
| Maximum operating distance |
300 m |
| Maximum indoor range |
100 m |
| Maximum outdoor range |
300 m |
| System requirements |
| Windows operating systems supported |
Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 7, Windows 7 Enterprise, W |
| Mac operating systems supported |
Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks |
| Linux operating systems supported |
Yes |
| Server operating systems supported |
Windows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2016, Windows Server 2019 |
| Weight & dimensions |
| Width |
15 mm |
| Depth |
19 mm |
| Height |
8 mm |
| Weight |
2.2 g |
| Ports & interfaces |
| Connectivity technology |
Wireless |
| Host interface |
USB |
| Interface |
WLAN |
| USB version |
2.0 |
| Operational conditions |
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-20 - 75 °C |
| Operating relative humidity (H-H) |
10 - 90% |
| Power |
| Output voltage |
5 V |
| USB powered |
Yes |
| Other features |
| Housing material |
Plastic |
| Design |
| Internal |
No |
| Component for |
PC/Laptop |
| Product colour |
Black |
| Chipset |
Realtek - RTL8188EUS |
| Plug and Play |
Yes |
| Mean time between failures (MTBF) |
44000 h |
| Certification |
CE, FCC, REACH |
| Logistics data |
| Harmonized System (HS) code |
85176990 |
| Packaging data |
| Drivers included |
Yes |
| Package width |
111 mm |
| Package depth |
172 mm |
| Package height |
14 mm |
| Package weight |
42 g |
| Technical details |
| Compliance certificates |
RoHS |
| Packaging content |
| Manual |
Yes |
