| Weight & dimensions |
| Width |
87 mm |
| Depth |
226 mm |
| Height |
28 mm |
| Weight |
301 g |
| Package width |
130 mm |
| Package depth |
318 mm |
| Package height |
52 mm |
| Package weight |
851 g |
| Ports & interfaces |
| Connectivity technology |
Wired |
| Host interface |
USB 3.2 Gen 1 (3.1 Gen 1) Type-C |
| USB 3.0 (3.1 Gen 1) Type-A ports quantity |
6 |
| Ethernet LAN (RJ-45) ports |
1 |
| HDMI ports quantity |
2 |
| Microphone in |
Y |
| Headphone outputs |
1 |
| DisplayPorts quantity |
2 |
| DC-in jack |
Y |
| Number of microphone inputs |
1 |
| Headphone connectivity |
3.5 mm |
| Combo headphone/mic port |
N |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
6 |
| Power |
| Power source type |
AC |
| AC input voltage |
100 - 240 V |
| Input current |
1 A |
| Output voltage |
20 V |
| Output current |
2 A |
| Power consumption (typical) |
40 W |
| Plug type |
Type N (BR) |
| Compatible power plug types |
AU, EU, JP, UK, US |
| Power plug type |
Type N |
| Storage |
| Card reader integrated |
N |
| Packaging content |
| Cables included |
USB Type-A to USB Type-C, USB Type-C |
| AC adapter included |
Y |
| Quick start guide |
Y |
| Other features |
| Chipset |
DisplayLink - DL-6950, VIA/VLI - VL813 |
| Cable length |
0.152 m |
| Number of microphone inputs |
1 |
| USB data transfer rates |
12,480,5000 Mbit/s |
| Operational conditions |
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-10 - 70 °C |
| Operating relative humidity (H-H) |
10 - 90% |
| Networking |
| Ethernet LAN |
Y |
| 10G support |
N |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Networking standards |
IEEE 802.3,IEEE 802.3ab,IEEE 802.3u |
| Ethernet LAN (RJ-45) ports |
1 |
| Auto MDI/MDI-X |
Y |
| Full duplex |
Y |
| Design |
| Product colour |
Black,Silver |
| LED indicators |
Power |
| Material |
Aluminium,Plastic |
| RoHS compliance |
Y |
| Certification |
CE, FCC, REACH |
| Performance |
| Brand compatibility |
Any brand |
| On/off switch |
Y |
| Data transfer rate |
5 Gbit/s |
| Auto MDI/MDI-X |
Y |
| Full duplex |
Y |
| Maximum digital resolution |
4096 x 2160 pixels |
| UASP support |
Y |
| USB data transfer rates |
12,480,5000 Mbit/s |
| Number of displays supported |
2 |
| Product colour |
Black, Silver |
| Card reader integrated |
N |
| LED indicators |
Power |
| Housing material |
Aluminium, Plastic |
| RoHS compliance |
Y |
| Certification |
CE, FCC, REACH |
| Technical details |
| Sustainability certificates |
RoHS |
| Software |
| Windows operating systems supported |
Windows 10,Windows 10 Education,Windows 10 Education x64,Windows 10 Enterprise,Windows 10 Enterprise x64,Windows 10 Home,Windows 10 Home x64,Windows 10 Pro,Windows 10 Pro x64,Windows 7,Windows 7 Enterprise,Windows 7 Enterprise x64,Windows 7 Home Basic,Win |
| Mac compatibility |
Y |
| Mac operating systems supported |
Mac OS X 10.11 El Capitan,Mac OS X 10.12 Sierra,Mac OS X 10.14 Mojave |
| Packaging data |
| Package width |
130 mm |
| Package depth |
318 mm |
| Package height |
52 mm |
| Package weight |
900 g |
| Logistics data |
| Products per master (outer) case |
10 pc(s) |
| Master (outer) case width |
32.5 cm |
| Master (outer) case length |
32.5 cm |
| Master (outer) case height |
30.5 cm |
| Sustainability |
| Sustainability certificates |
RoHS |
