| Weight & dimensions |
| Width |
106 mm |
| Depth |
223 mm |
| Height |
166 mm |
| Weight |
1.51 kg |
| Power |
| Power supply location |
External |
| Power supply unit (PSU) capacity |
65 W |
| Number of power supply units |
1 |
| Power consumption (typical) |
21.07 W |
| Power consumption (HDD standby) |
8.62 W |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50 / 60 Hz |
| Operational conditions |
| Operating temperature (T-T) |
0 - 40 °C |
| Operating relative humidity (H-H) |
5 - 95% |
| Storage temperature (T-T) |
-20 - 60 °C |
| Storage relative humidity (H-H) |
5 - 95% |
| Networking |
| Ethernet LAN |
Y |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Ethernet LAN data rate supported (max) |
10000 Mbit/s |
| Copper ethernet cabling technology |
10BASE-T, 100BASE-TX, 1000BASE-T |
| iSCSI support |
Y |
| Wake-on-LAN ready |
Y |
| Supported network protocols |
SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV |
| Link aggregation |
Y |
| Ports & interfaces |
| Ethernet LAN (RJ-45) ports |
2 |
| USB port |
Y |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
1 |
| eSATA ports quantity |
1 |
| Concurrent connections |
500 |
| PCI Express x2 (Gen 3.x) slots |
1 |
| Memory |
| Internal memory |
2 GB |
| Internal memory type |
DDR4 |
| Maximum RAM supported |
32 GB |
| Memory slots |
2 |
| Memory form factor |
SO-DIMM |
| ECC |
Y |
| Certificates |
| Certification |
FCC
BSMI
VCCI
RCM
UKCA
EAC
CCC
KC |
| Processor |
| Processor family |
AMD Ryzen |
| Processor manufacturer |
AMD |
| Processor model |
R1600 |
| Processor frequency |
2.6 GHz |
| Processor boost frequency |
3.1 GHz |
| Processor cores |
2 |
| Number of processors supported |
1 |
| Storage |
| Storage drives installed |
N |
| Number of storage drives supported |
2 |
| Installed storage drive type |
N |
| Supported storage drive types |
HDD & SSD |
| RAID support |
Y |
| Supported storage drive interfaces |
Serial ATA II, Serial ATA III |
| Storage drive sizes supported |
2.5,3.5,M.2 |
| Number of M.2 (M & B) slots |
2 |
| RAID levels |
0, 1, 5, 6, 10, JBOD |
| Online RAID migration |
Y |
| Online RAID expansion |
Y |
| Hot-swap drive bays |
Y |
| Supported file systems |
BTRFS, Fat, HFS+, NTFS, exFAT, ext3, ext4 |
| Packaging content |
| External power adapter |
Y |
| Cables included |
AC, LAN (RJ-45) |
| Power cables quantity |
1 |
| Performance |
| Type |
NAS |
| Device class |
Home & Home Office |
| Backup function |
Y |
| Backup features |
Cloud, iSCSI LUN |
| Multilingual support |
Y |
| Noise level |
20.7 dB |
| Video input channels |
2 channels |
| Management protocols |
SNMP |
| Security algorithms |
AES, HTTPS, SSH, SSL/TLS |
| Access Control List (ACL) |
Y |
| Reset button |
Y |
| On/off switch |
Y |
| Built-in FTP server |
Y |
| Browser supported |
Google Chrome, Firefox, Microsoft Edge, Safari |
| System log |
Y |
| Design |
| Chassis type |
Tower |
| Cooling type |
Active |
| Product colour |
Black |
| Number of fans |
1 fan(s) |
| Fan diameter |
9.2 cm |
| Drive bay locking |
Y |
| LED indicators |
Y |
| Built-in display |
N |
| Cable lock slot |
Y |
| Cable lock slot type |
Kensington |
| Built-in speaker(s) |
N |
| Technical details |
| Sustainability compliance |
Y |
| Sustainability certificates |
CE, RoHS |
| Software |
| Operating system installed |
DiskStation Manager |
| Operating system version |
7.1.1 |
| Server operating systems supported |
Windows Server 2016, Windows Server 2019 |
