| Weight & dimensions |
| Width |
300 mm |
| Depth |
340 mm |
| Height |
270 mm |
| Weight |
9.8 kg |
| Power |
| Power supply location |
Built-in |
| Power supply unit (PSU) capacity |
550 W |
| Number of power supply units |
1 |
| Power consumption (typical) |
94.42 W |
| Power consumption (HDD standby) |
54.33 W |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50 - 60 Hz |
| Operational conditions |
| Operating temperature (T-T) |
0 - 40 °C |
| Operating relative humidity (H-H) |
5 - 95% |
| Storage temperature (T-T) |
-20 - 60 °C |
| Networking |
| Ethernet LAN |
Y |
| Ethernet LAN data rates |
1000,10000 Mbit/s |
| Wake-on-LAN ready |
Y |
| Supported network protocols |
SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV |
| Link aggregation |
Y |
| Ports & interfaces |
| Ethernet LAN (RJ-45) ports |
4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
2 |
| PCI Express x8 (Gen 3.x) slots |
1 |
| Memory |
| Internal memory |
16 GB |
| Internal memory type |
DDR4 |
| Maximum RAM supported |
48 GB |
| Memory slots |
4 |
| Memory form factor |
SO-DIMM |
| Certificates |
| Certification |
FCC
CE
BSMI
VCCI
RCM
UKCA
EAC
KC
UL |
| Processor |
| Processor family |
Intel® Xeon® D |
| Processor manufacturer |
Intel |
| Processor model |
D-1531 |
| Processor frequency |
2.2 GHz |
| Processor boost frequency |
2.7 GHz |
| Processor cores |
6 |
| CPU configuration (max) |
1 |
| Number of processors supported |
1 |
| Conflict-Free processor |
Y |
| Storage |
| Storage drives installed |
N |
| Number of storage drives supported |
12 |
| Installed storage drive type |
N |
| Supported storage drive types |
HDD & SSD |
| RAID support |
Y |
| Supported storage drive interfaces |
Serial ATA, Serial ATA II, Serial ATA III |
| Storage drive sizes supported |
2.5,3.5" |
| Maximum supported storage capacity |
200 TB |
| RAID levels |
0,1,5,6,10,JBOD |
| Hot-swap drive bays |
Y |
| Supported file systems |
BTRFS, Fat, HFS+, NTFS, ext3, ext4 |
| Packaging content |
| Cables included |
AC, LAN (RJ-45) |
| Performance |
| Type |
NAS |
| Device class |
Home & Home Office |
| Backup function |
Y |
| Multilingual support |
Y |
| Noise level |
25 dB |
| Web-based management |
Y |
| Access Control List (ACL) |
Y |
| Browser supported |
Safari, Google Chrome, Firefox, Microsoft Edge |
| Design |
| Chassis type |
Tower |
| Cooling type |
Active |
| Product colour |
Black |
| Number of fans |
2 fan(s) |
| Fan diameter |
12 cm |
| Processor special features |
| Embedded options available |
N |
| Enhanced Intel SpeedStep Technology |
Y |
| Execute Disable Bit |
Y |
| Idle States |
Y |
| Intel 64 |
Y |
| Intel Enhanced Halt State |
Y |
| Intel Secure Key Technology version |
1.00 |
| Intel Trusted Execution Technology |
Y |
| Intel TSX-NI |
Y |
| Intel TSX-NI version |
1.00 |
| Intel Virtualization Technology (VT-x) |
Y |
| Intel Virtualization Technology for Directed I/O (VT-d) |
Y |
| Intel VT-x with Extended Page Tables (EPT) |
Y |
| Software |
| Operating system installed |
DiskStation Manager |
| Server operating systems supported |
Windows Server 2016,Windows Server 2019 |
