| Memory |
| Internal memory |
16 GB |
| Internal memory type |
DDR4-SDRAM |
| Maximum internal memory |
64 GB |
| Buffered memory type |
Unregistered (unbuffered) |
| Memory slots |
4x DIMM |
| ECC |
Yes |
| Memory clock speed |
3200 MHz |
| Memory layout (slots x size) |
1 x 16 GB |
| Processor |
| Processor family |
Intel Xeon E |
| Processor manufacturer |
Intel |
| Processor model |
E-2314 |
| Processor frequency |
2.8 GHz |
| Processor boost frequency |
4.5 GHz |
| Processor cache |
8 MB |
| Number of processors installed |
1 |
| Execute Disable Bit |
Yes |
| Idle States |
Yes |
| Ports & interfaces |
| Ethernet LAN (RJ-45) ports |
2 |
| USB 2.0 ports quantity |
5 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
2 |
| VGA (D-Sub) ports quantity |
1 |
| Serial ports quantity |
1 |
| Networking |
| LAN controller |
Broadcom 5720 |
| Ethernet LAN |
Yes |
| Cabling technology |
10/100/1000Base-T(X) |
| Ethernet interface type |
Gigabit Ethernet |
| Weight & dimensions |
| Width |
175 mm |
| Depth |
453.8 mm |
| Height |
360 mm |
| Weight |
11.7 kg |
| Power |
| Power supply |
300 W |
| Number of main power supplies |
1 |
| Storage |
| Total storage capacity |
2 TB |
| RAID support |
No |
| Optical drive type |
No |
| Number of HDDs installed |
1 |
| HDD capacity |
2 TB |
| HDD interface |
SATA |
| HDD speed |
7200 RPM |
| HDD size |
3.5" |
| Supported RAID controllers |
PERC H355 |
| Graphics |
| On-board graphics card model |
Not available |
| Other features |
| Data transfer rate |
6 Gbit/s |
| Bytes per sector |
512n |
| Performance |
| Remote administration |
iDRAC9 Basic 15G |
| Design |
| Chassis type |
Mini Tower |
| Product colour |
Black |
| Operating system/software |
| Operating system installed |
No |
| Compatible operating systems |
Microsoft Windows Server with Hyper-V
Red Hat Enterprise Linux
SUSE Linux Enterprise Server
Citrix Hypervisor
Canonical Ubuntu Server LTS |
| Software |
| Operating system installed |
No |
| Compatible operating systems |
Microsoft Windows Server with Hyper-V
Red Hat Enterprise Linux
SUSE Linux Enterprise Server
Citrix Hypervisor
Canonical Ubuntu Server LTS |
| Processor special features |
| CPU configuration (max) |
1 |
| Enhanced Intel SpeedStep Technology |
Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) |
Yes |
| Intel Trusted Execution Technology |
Yes |
| Intel VT-x with Extended Page Tables (EPT) |
Yes |
| Intel Software Guard Extensions (Intel SGX) |
Yes |
| Intel 64 |
Yes |
| Intel Virtualization Technology (VT-x) |
Yes |
| Logistics data |
| Harmonized System (HS) code |
84714100 |
| Carbon footprint |
| Total carbon footprint (kg of CO2e) |
2230 |
| Total carbon emissions, standard deviation (kg of CO2e) |
1010 |
| Carbon emissions, manufacturing (kg of CO2e) |
457.2 |
| Carbon emissions, logistics (kg of CO2e) |
139 |
| Carbon emissions, energy usage (kg of CO2e) |
1610 |
| Carbon emissions, end-of-life (kg of CO2e) |
20.9 |
| PAIA version |
1.3.2, 2022 |
