Stock Status: 1x unit in stock
Immerse yourself in the TCL 505's sleek design and unparalleled audiovisual experience. Featuring a 6.75" HD+ display with a 90Hz refresh rate, and enhanced by NXTVISION & NXTURBO technologies, it delivers a seamlessly smooth visual experience with sharp clarity and deeper details for streaming, gaming, and browsing. Capture highly detailed photos, exquisite macros, and artistic portraits with the 50MP dual 2-in-1 Hybrid camera., and never worry about storage limitations with 128GB memory for all your favourite photos, videos, and media. Effortlessly multitask with up to 8GB of RAM, 4GB powered by TCL’s RAM Expansion, enabling you to keep more applications open in the background without compromising performance, and with TCL's intelligent power-saving modes and a robust 5010mAh battery, you can stream, game, and browse worry-free all day long.
Specs
| Weight & dimensions |
| Weight |
190 g |
| Width |
76.7 mm |
| Depth |
8.32 mm |
| Height |
168.3 mm |
| Display |
| Display diagonal |
17.1 cm (6.75") |
| Display resolution |
720 x 1600 pixels |
| Screen shape |
Flat |
| Display technology marketing name |
NXTVISION |
| Display glass type |
2.5D tempered glass |
| Display brightness |
400 cd/m² |
| Touchscreen type |
Capacitive |
| Pixel density |
260 ppi |
| Oleophobic coating |
Yes |
| Processor |
| Processor family |
MediaTek Dimensity |
| Processor model |
Helio G36 |
| Processor frequency |
2.2 GHz |
| Processor architecture |
ARM Cortex-A53 |
| Processor cores |
4 |
| Coprocessor frequency |
1.6 GHz |
| Coprocessor architecture |
ARM Cortex-A53 |
| Coprocessor cores |
4 |
| Storage |
| RAM capacity |
8 GB |
| Internal storage capacity |
128 GB |
| Compatible memory cards |
MicroSD (TransFlash) |
| User memory |
108 GB |
| Maximum memory card size |
512 GB |
| Camera |
| Rear camera type |
Dual camera |
| Rear camera resolution (numeric) |
50 MP |
| Front camera type |
Single camera |
| Front camera resolution (numeric) |
5 MP |
| Rear camera flash |
Yes |
| Rear camera sensor size |
1/2.55" |
| Second rear camera sensor size |
1/5" |
| Second rear camera resolution (numeric) |
2 MP |
| Rear camera aperture number |
1.8 |
| Second rear camera aperture number |
2.4 |
| Rear camera pixel size |
0.7 µm |
| Second rear camera pixel size |
1.75 µm |
| Rear camera field of view (FOV) angle |
79.4° |
| Second rear camera field of view (FOV) angle |
88.8° |
| Rear camera lens elements |
5-element lens |
| Second rear camera lens elements |
3-element lens |
| Front camera lens elements |
3-element lens |
| Front camera aperture number |
2.2 |
| Front camera pixel size |
1.12 µm |
| Front camera field of view (FOV) angle |
76.8° |
| Resolution at capture speed |
1920x1080@30fps |
| Video recording modes |
1080p |
| Face detection |
Yes |
| Camera High Dynamic Range (HDR) mode |
Yes |
| Panorama |
Yes |
| AI scene recognition |
Yes |
| Ports & interfaces |
| USB port |
Yes |
| USB connector type |
USB Type-C |
| USB version |
2.0 |
| Headphone connectivity |
3.5 mm |
| Networking |
| SIM card capability |
Hybrid Dual SIM |
| Mobile network generation |
4G |
| SIM card type |
NanoSIM |
| 5G standard |
Not supported |
| Wi-Fi |
Yes |
| Bluetooth |
Yes |
| Voice over LTE (VoLTE) supported |
Yes |
| Wi-Fi standards |
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Bluetooth version |
5.1 |
| Wi-Fi Direct |
Yes |
| Near Field Communication (NFC) |
Yes |
| Battery |
| Battery capacity |
5010 mAh |
| Battery recharge time |
3 h |
| Packaging content |
| Quick start guide |
Yes |
| Cables included |
USB Type-C |
| SIM card ejector pin |
Yes |
| Performance |
| Graphics card |
IMG GE8320 |
| Design |
| Form factor |
Bar |
| Product colour |
Blue |
| Navigation |
| Position location |
Yes |
| Assisted GPS (A-GPS) |
Yes |
| GPS (satellite) |
Yes |
| GLONASS |
Yes |
| BeiDou |
Yes |
| Galileo |
Yes |
| Multimedia |
| Audio formats supported |
AAC, AMR, AWB, FLAC, HE-AAC, HE-AAC v2, MIDI, MP3, OGG, OPUS, Vorbis, WAV |
| Video formats supported |
H.263, H.264, H.265, MPEG2, MPEG4, VP8, VP9 |
| Software |
| Platform |
Android |
| Operating system installed |
Android 14 |
| Subscription |
| Subscription type |
No subscription |
| Sensors |
| Proximity sensor |
Yes |
| Accelerometer |
Yes |
Features
TCL 505. Display diagonal: 17.1 cm (6.75"), Display resolution: 720 x 1600 pixels. Processor frequency: 2.2 GHz, Processor family: MediaTek Dimensity, Processor model: Helio G36. RAM capacity: 8 GB, Internal storage capacity: 128 GB. Rear camera resolution (numeric): 50 MP, Rear camera type: Dual camera. SIM card capability: Hybrid Dual SIM. Operating system installed: Android 14. Battery capacity: 5010 mAh. Product colour: Blue. Weight: 190 g
Product Description
Immerse yourself in the TCL 505's sleek design and unparalleled audiovisual experience. Featuring a 6.75" HD+ display with a 90Hz refresh rate, and enhanced by NXTVISION & NXTURBO technologies, it delivers a seamlessly smooth visual experience with sharp clarity and deeper details for streaming, gaming, and browsing. Capture highly detailed photos, exquisite macros, and artistic portraits with the 50MP dual 2-in-1 Hybrid camera., and never worry about storage limitations with 128GB memory for all your favourite photos, videos, and media. Effortlessly multitask with up to 8GB of RAM, 4GB powered by TCL’s RAM Expansion, enabling you to keep more applications open in the background without compromising performance, and with TCL's intelligent power-saving modes and a robust 5010mAh battery, you can stream, game, and browse worry-free all day long.
