Stock Status: 1x unit in stock
The Lenovo ThinkSystem SR630 V3 is an ideal 2-socket 1U rack server for small businesses up to large enterprises that need industry-leading reliability, management, and security, as well as maximizing performance and flexibility for future growth. The SR630 V3 is designed to handle a wide range of workloads, such as databases, virtualization and cloud computing, virtual desktop infrastructure (VDI), infrastructure security, systems management, enterprise applications, collaboration/email, streaming media, web, and HPC.
This product guide provides essential pre-sales information to understand the ThinkSystem SR630 V3 server, its key features and specifications, components and options, and configuration guidelines. This guide is intended for technical specialists, sales specialists, sales engineers, IT architects, and other IT professionals who want to learn more about the SR630 V3 and consider its use in IT solutions.
Specs
| Memory |
| Internal memory |
32 GB |
| Internal memory type |
DDR5-SDRAM |
| Maximum internal memory |
8.19 TB |
| Memory slots |
32x DIMM |
| ECC |
Yes |
| Memory clock speed |
5600 MHz |
| Memory layout (slots x size) |
1 x 32 GB |
| Processor |
| Processor family |
Intel Xeon Silver |
| Processor manufacturer |
Intel |
| Processor model |
4510 |
| Processor frequency |
2.4 GHz |
| Processor boost frequency |
4.1 GHz |
| Processor cores |
12 |
| Processor cache |
30 MB |
| Number of processors installed |
1 |
| Maximum number of SMP processors |
2 |
| Ports & interfaces |
| Ethernet LAN (RJ-45) ports |
1 |
| USB 2.0 ports quantity |
2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
3 |
| VGA (D-Sub) ports quantity |
1 |
| Weight & dimensions |
| Width |
440 mm |
| Depth |
773 mm |
| Height |
43 mm |
| Power |
| Redundant power supply (RPS) support |
Yes |
| Power supply |
1100 W |
| Power supply input frequency |
50 - 60 Hz |
| Operational conditions |
| Operating temperature (T-T) |
5 - 45 °C |
| Storage temperature (T-T) |
-40 - 60 °C |
| Operating relative humidity (H-H) |
8 - 90% |
| Storage relative humidity (H-H) |
8 - 90% |
| Operating altitude |
0 - 3050 m |
| Storage |
| RAID support |
Yes |
| Optical drive type |
No |
| RAID levels |
0, 1, 5, 6, 10, 50, 60 |
| Supported RAID controllers |
9350-8i |
| Hot-swap |
Yes |
| Internal drive bays |
8 |
| Supported storage drive interfaces |
SAS |
| Graphics |
| On-board graphics card |
Yes |
| Maximum graphics card memory |
16 MB |
| Performance |
| Performance management |
XClarity Controller Platinum |
| Trusted Platform Module (TPM) |
Yes |
| Trusted Platform Module (TPM) version |
2.0 |
| Design |
| Chassis type |
Rack (1U) |
| Technical details |
| 2.5" HDD support |
8 |
| Operating system/software |
| Compatible operating systems |
Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi, Ubuntu Server |
| Software |
| Compatible operating systems |
Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi, Ubuntu Server |
Features
Lenovo ThinkSystem SR630 V3. Processor family: Intel Xeon Silver, Processor frequency: 2.4 GHz, Processor model: 4510. Internal memory: 32 GB, Internal memory type: DDR5-SDRAM, Memory layout (slots x size): 1 x 32 GB. Power supply: 1100 W, Redundant power supply (RPS) support. Chassis type: Rack (1U)
Product Description
The Lenovo ThinkSystem SR630 V3 is an ideal 2-socket 1U rack server for small businesses up to large enterprises that need industry-leading reliability, management, and security, as well as maximizing performance and flexibility for future growth. The SR630 V3 is designed to handle a wide range of workloads, such as databases, virtualization and cloud computing, virtual desktop infrastructure (VDI), infrastructure security, systems management, enterprise applications, collaboration/email, streaming media, web, and HPC.
This product guide provides essential pre-sales information to understand the ThinkSystem SR630 V3 server, its key features and specifications, components and options, and configuration guidelines. This guide is intended for technical specialists, sales specialists, sales engineers, IT architects, and other IT professionals who want to learn more about the SR630 V3 and consider its use in IT solutions.
