Weight & dimensions |
Width |
444 mm |
Depth |
744 mm |
Height |
130.8 mm |
Weight |
22.4 kg |
Package weight |
30.2 kg |
Power |
Power supply location |
Built-in |
Power supply unit (PSU) capacity |
770 W |
Redundant power supply (RPS) support |
Y |
Power consumption (typical) |
362.86 W |
Power consumption (sleep) |
254.21 W |
AC input voltage |
100 - 240 V |
AC input frequency |
50 - 60 Hz |
Fan voltage |
12 V |
Operational conditions |
Operating temperature (T-T) |
0 - 40 °C |
Operating relative humidity (H-H) |
5 - 95% |
Networking |
Ethernet LAN |
Y |
Ethernet LAN data rates |
10,100,1000,10000 Mbit/s |
Ethernet LAN data rate supported (max) |
10000 Mbit/s |
Wi-Fi |
N |
DHCP client |
Y |
DHCP server |
Y |
Jumbo frames support |
Y |
iSCSI support |
Y |
Wake-on-LAN ready |
Y |
Link aggregation |
Y |
Ports & interfaces |
Ethernet LAN (RJ-45) ports |
3 |
USB port |
Y |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
4 |
Fiber ports quantity |
4 |
Fiber optic connector |
SFP+ |
VGA (D-Sub) ports quantity |
1 |
PCI Express x8 (Gen 3.x) slots |
3 |
Memory |
Internal memory |
256 GB |
Internal memory type |
DDR4 |
Memory clock speed |
2400 MHz |
Maximum RAM supported |
1000 GB |
Memory slots |
16x RDIMM/LRDIMM |
Flash memory |
4096 MB |
Processor |
Processor family |
Intel® Xeon® E5 v4 |
Processor manufacturer |
Intel |
Processor model |
E5-2630V4 |
Processor frequency |
2.2 GHz |
Processor boost frequency |
3.1 GHz |
Processor cores |
10 |
Processor threads |
20 |
Processor cache |
25 MB |
Bus type |
QPI |
CPU configuration (max) |
2 |
PCI Express slots version |
3.0 |
Physical Address Extension (PAE) |
46 bit |
Processor cache type |
Smart Cache |
Processor code |
SR2R7 |
Processor codename |
Broadwell |
Processor lithography |
14 nm |
Processor operating modes |
64-bit |
Processor package size |
45 x 52.5 mm |
Processor series |
Intel Xeon E5-2600 v4 |
Processor socket |
LGA 2011-v3 |
Scalability |
2S |
Stepping |
R0 |
System bus rate |
8 GT/s |
Tcase |
74 °C |
Thermal Design Power (TDP) |
85 W |
Maximum internal memory supported by processor |
1536 GB |
Memory bandwidth supported by processor (max) |
68.3 GB/s |
Conflict-Free processor |
Y |
Other features |
Processor ARK ID |
92981 |
Storage |
Storage drives installed |
Y |
Total installed storage capacity |
64 TB |
Number of storage drives supported |
20 |
Installed storage drive type |
HDD |
Supported storage drive types |
HDD & SSD |
RAID support |
Y |
Supported storage drive interfaces |
Near Line SAS (NL-SAS), Serial ATA |
Storage drive sizes supported |
2.5,3.5" |
RAID levels |
0, 1, 5+S, 5, 6, 6+HS, 10+HS, 10, 50, 60, JBOD |
Online RAID migration |
Y |
Online RAID expansion |
Y |
Hot-swap drive bays |
Y |
Packaging content |
Cables included |
AC, LAN (RJ-45) |
Quick installation guide |
Y |
Number of screws |
128 |
Performance |
Type |
NAS |
Device class |
Large Enterprise Business |
Backup function |
Y |
Backup features |
Cloud |
Buzzer |
Y |
Noise level |
37.8 dB |
Video input channels |
8 channels |
Snapshot |
Y |
Management protocols |
SNMP |
Web-based management |
Y |
Share folder access right management |
Y |
Security algorithms |
SSH |
Access Control List (ACL) |
Y |
Reset button |
Y |
On/off switch |
Y |
Built-in FTP server |
Y |
Browser supported |
Google Chrome, Microsoft Internet Explorer, Mozilla Firefox, Apple Safari |
System log |
Y |
Hot spare |
Y |
S.M.A.R.T. support |
Y |
Design |
Chassis type |
Rack (3U) |
Cooling type |
Active |
Product colour |
Aluminium, Black |
Number of fans |
4 fan(s) |
Fan diameter |
6 cm |
LED indicators |
HDD, LAN, Status |
Processor special features |
Embedded options available |
N |
Enhanced Intel SpeedStep Technology |
Y |
Execute Disable Bit |
Y |
Idle States |
Y |
Intel 64 |
Y |
Intel Demand Based Switching |
Y |
Intel Enhanced Halt State |
Y |
Intel Flex Memory Access |
N |
Intel Identity Protection Technology version |
0.00 |
Intel Secure Key Technology version |
1.00 |
Intel Trusted Execution Technology |
Y |
Intel TSX-NI |
Y |
Intel TSX-NI version |
1.00 |
Intel Virtualization Technology (VT-x) |
Y |
Intel Virtualization Technology for Directed I/O (VT-d) |
Y |
Intel VT-x with Extended Page Tables (EPT) |
Y |
Intel® AES New Instructions (Intel® AES-NI) |
Y |
Intel® Hyper Threading Technology (Intel® HT Technology) |
Y |
Intel® Identity Protection Technology (Intel® IPT) |
N |
Intel® OS Guard |
Y |
Intel® Secure Key |
Y |
Intel® Turbo Boost Technology |
2.0 |
Maximum number of PCI Express lanes |
40 |
Number of QPI links |
2 |
Physical Address Extension (PAE) |
Y |
Thermal Monitoring Technologies |
Y |
Memory types supported by processor |
DDR4-SDRAM |
Software |
Windows operating systems supported |
Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x |
Linux operating systems supported |
Y |
Mac operating systems supported |
Y |
Server operating systems supported |
Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016 |
