| Wireless LAN features |
| Wi-Fi band |
Dual-band (2.4 GHz / 5 GHz) |
| Top Wi-Fi standard |
Wi-Fi 5 (802.11ac) |
| WLAN data transfer rate (max) |
867 Mbit/s |
| Wi-Fi standards |
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| WLAN data transfer rate (first band) |
450 Mbit/s |
| WLAN data transfer rate (second band) |
867 Mbit/s |
| Ports & interfaces |
| Ethernet LAN (RJ-45) ports |
5 |
| USB port |
No |
| Memory card slot(s) |
No |
| DC-in jack |
Yes |
| Mobile networking |
| 3G |
No |
| 4G |
No |
| Networking |
| Ethernet LAN |
Yes |
| Ethernet LAN interface type |
Fast Ethernet |
| Ethernet LAN data rates |
10,100 Mbit/s |
| Cabling technology |
10/100Base-T(X) |
| Networking standards |
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Port forwarding |
Yes |
| VPN Passthrough |
Yes |
| VPN support |
PPTP, L2TP, IPSec |
| Receiver sensitivity |
5GHz: 11a 54M: -76dBm
11ac VHT20 MCS8: -70dBm
11ac VHT40 MCS9: -65.5dBm
11ac VHT80 MCS9: -61.5dBm
2.4G: 11g 54M: -76dBm
11n HT20 MCS7: -74dBm
11n HT40 MCS7: -71dBm |
| Protocols |
| DHCP client |
Yes |
| DHCP server |
Yes |
| Universal Plug and Play (UPnP) |
Yes |
| VoIP protocols |
IPv4, IPv6 |
| Antenna |
| Antenna design |
External |
| Antennas quantity |
5 |
| Transmit power |
CE: <20dBm(2.4GHz), <23dBm(5GHz) |
| Management features |
| Reset button |
Yes |
| WPS push button |
Yes |
| Security |
| Security algorithms |
64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK |
| Firewall |
Yes |
| Guest access |
Yes |
| Stateful Packet Inspection (SPI) |
Yes |
| DoS attack prevention |
Yes |
| Filtering |
Yes |
| MAC address filtering |
Yes |
| IP address filtering |
Yes |
| DMZ support |
Yes |
| Power |
| Power source type |
AC |
| Output voltage |
12 V |
| Output current |
1 A |
| Weight & dimensions |
| Width |
215 mm |
| Depth |
117 mm |
| Height |
32 mm |
| System requirements |
| Windows operating systems supported |
Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Hom |
| Linux operating systems supported |
Yes |
| Mac operating systems supported |
macOS |
| Mac compatibility |
Yes |
| Operational conditions |
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-40 - 70 °C |
| Operating relative humidity (H-H) |
10 - 90% |
| Storage relative humidity (H-H) |
5 - 90% |
| Design |
| Product type |
Tabletop router |
| Product colour |
White |
| Indication light |
Yes |
| LED indicators |
LAN, Power, WLAN |
| On/off switch |
Yes |
| Other features |
| Maximum data transfer rate |
1 Mbit/s |
| WAN connection |
| Ethernet WAN |
Yes |
| DSL WAN |
No |
| SIM card slot |
No |
| 3G/4G USB modem compatibility |
No |
| WAN connection type |
RJ-45 |
| Logistics data |
| Harmonized System (HS) code |
85176990 |
| Packaging data |
| Package width |
350 mm |
| Package depth |
240 mm |
| Package height |
82 mm |
| Package weight |
870 g |
| Package type |
Box |
| Packaging content |
| Cables included |
LAN (RJ-45) |
| AC adapter included |
Yes |
| Manual |
Yes |
| Quick installation guide |
Yes |
| Quick start guide |
Yes |
