| Networking |
| Maximum data transfer rate |
867 Mbit/s |
| Networking standards |
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Wi-Fi |
Y |
| Wi-Fi band |
Dual-band (2.4 GHz / 5 GHz) |
| Top Wi-Fi standard |
Wi-Fi 5 (802.11ac) |
| Wi-Fi standards |
802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| WLAN data transfer rates supported |
11,54,300,867 Mbit/s |
| Modulation |
16-QAM, 64-QAM, 256-QAM, CCK, DBPSK, DQPSK, OFDM |
| Bandwidth (first) |
2.4 GHz |
| Bandwidth (second) |
5 GHz |
| Security algorithms |
64-bit WEP, 128-bit WEP, 802.1x RADIUS, WPA, WPA-PSK, WPA2, WPA2-PSK |
| System requirements |
| Windows operating systems supported |
Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows |
| Weight & dimensions |
| Width |
120.8 mm |
| Depth |
115.2 mm |
| Height |
21.5 mm |
| Ports & interfaces |
| Connectivity technology |
Wireless |
| Host interface |
PCI Express |
| Interface |
WLAN |
| PCI Card form factor |
Half-height (low-profile) |
| Operational conditions |
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-40 - 70 °C |
| Operating relative humidity (H-H) |
10 - 90% |
| Storage relative humidity (H-H) |
5 - 90% |
| Other features |
| Detachable antenna(s) |
Y |
| Antennas quantity |
2 |
| Transmit power range |
59.5 - 92 dBmW |
| Conflict-Free |
Y |
| Harmonized System (HS) code |
85176990 |
| Design |
| Internal |
Y |
| Component for |
PC |
| Product colour |
Black, Green |
| Antenna |
Y |
| Antenna design |
External |
| Certification |
CE, FCC |
| Transmitting power (CE) |
23 dBm |
| Transmitting power (FCC) |
24 dBm |
| Operating modes |
Infrastructure mode |
| Logistics data |
| Harmonized System (HS) code |
85176990 |
| Packaging data |
| Quantity |
1 |
| Low-profile bracket |
Y |
| Package type |
Box |
| Package width |
207 mm |
| Package depth |
148 mm |
| Package height |
42 mm |
| Package weight |
300 g |
| Packaging content |
| Quick installation guide |
Y |
| Mounting brackets included |
Y |
| Resource CD |
Y |
| Sustainability |
| Sustainability certificates |
RoHS, Federal Communications Commission (FCC), CE |
| Sustainability compliance |
Y |
