| Networking |
| Maximum data transfer rate |
2402 Mbit/s |
| Networking standards |
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Wi-Fi |
Yes |
| Wi-Fi band |
Dual-band (2.4 GHz / 5 GHz) |
| Frequency range |
2.4 - 5 GHz |
| Top Wi-Fi standard |
Wi-Fi 6 (802.11ax) |
| Wi-Fi standards |
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
| WLAN data transfer rates supported |
54,300,574,1733,2402 Mbit/s |
| Modulation |
16-QAM, 64-QAM, 256-QAM, CCK, DBPSK, DQPSK, OFDM |
| Security algorithms |
64-bit WEP, 128-bit WEP, 802.1x RADIUS, WPA, WPA-PSK, WPA2, WPA2-PSK, WPA3 |
| Bluetooth |
Yes |
| Bluetooth version |
5.0 |
| System requirements |
| Windows operating systems supported |
Windows 10 Education x64, Windows 10 Enterprise x64, Windows 10 Home x64, Windows 10 Pro x64, Windows 10 x64 |
| Weight & dimensions |
| Width |
95.2 mm |
| Depth |
120.8 mm |
| Height |
21.5 mm |
| Ports & interfaces |
| Connectivity technology |
Wireless |
| Host interface |
PCI Express |
| Interface |
WLAN / Bluetooth |
| Operational conditions |
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-40 - 70 °C |
| Operating relative humidity (H-H) |
10 - 90% |
| Storage relative humidity (H-H) |
5 - 90% |
| Design |
| Internal |
Yes |
| Component for |
PC |
| Product colour |
Black, Red |
| Antenna |
Yes |
| Antenna design |
External |
| Transmitting power (CE) |
23 dBm |
| Transmitting power (FCC) |
27 dBm |
| Chipset |
Intel Wi-Fi 6 |
| Receiver sensitivity |
5 GHz :
11ax HT160：-56.25dBm
11ax HT80: -59dBm
11ax HT40: -62.25dBm
11ax HT20: -65dBm
11ac HT160：-62dBm
11ac HT80: -65.5dBm
11ac HT40: -69.75dBm
11ac HT20: -73.75dBm
11n HT40: -74.5dBm
11n HT20: -77.5dBm
11a 54Mbps: -77.75dBm
11a 6Mbps: -94.5dBm
2.4GHz |
| Operating modes |
Infrastructure mode |
| Logistics data |
| Harmonized System (HS) code |
85176990 |
| Packaging data |
| Package width |
270 mm |
| Package depth |
215 mm |
| Package height |
47 mm |
| Package weight |
480 g |
| Technical details |
| Compliance certificates |
CE, Federal Communications Commission (FCC), RoHS |
| Packaging content |
| Mounting brackets included |
Yes |
| Resource CD |
Yes |
| Bluetooth header cable |
Yes |
| Quick installation guide |
Yes |
| Sustainability |
| Sustainability compliance |
Yes |
