| Wireless LAN features |
| Wi-Fi band |
Dual-band (2.4 GHz / 5 GHz) |
| Top Wi-Fi standard |
Wi-Fi 5 (802.11ac) |
| WLAN data transfer rate (max) |
867 Mbit/s |
| Wi-Fi standards |
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Channels quantity |
2 channels |
| Ports & interfaces |
| Ethernet LAN (RJ-45) ports |
4 |
| USB port |
Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
1 |
| DC-in jack |
Yes |
| DSL features |
| ADSL |
Yes |
| ADSL2 |
Yes |
| ADSL2+ |
Yes |
| VDSL |
Yes |
| VDSL2 |
Yes |
| Internal modem |
Yes |
| Networking |
| Ethernet LAN |
Yes |
| Ethernet LAN interface type |
Gigabit Ethernet |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Cabling technology |
10/100/1000Base-T(X) |
| Networking standards |
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u |
| Port forwarding |
Yes |
| Port triggering |
Yes |
| Dynamic DNS (DDNS) |
Yes |
| Static route |
Yes |
| USB sharing |
Yes |
| Support Samba (storage) |
Yes |
| Built-in FTP server |
Yes |
| Media server |
Yes |
| VPN support |
OpenVPN, PPTP VPN, IPSec VPN |
| Protocols |
| DHCP client |
Yes |
| DHCP server |
Yes |
| Universal Plug and Play (UPnP) |
Yes |
| Switching protocols |
IPv4, IPv6 |
| Routing protocols |
RIP-1, RIP-2 |
| Management protocols |
HTTP / HTTPS, SSL |
| Antenna |
| Antenna design |
Internal |
| Antenna gain level (max) |
2 dBi |
| Antenna direction type |
Omni-directional |
| Management features |
| Web-based management |
Yes |
| Wi-Fi Multimedia (WMM)/(WME) |
Yes |
| Quality of Service (QoS) support |
Yes |
| Reset button |
Yes |
| WPS push button |
Yes |
| MU-MIMO technology |
Yes |
| Security |
| Security algorithms |
64-bit WEP, 128-bit WEP, IPSec, WPA, WPA-PSK, WPA2, WPA-PSK2 |
| Firewall |
Yes |
| Firewall security |
NAT, SPI |
| Guest access |
Yes |
| Access Control List (ACL) |
Yes |
| Stateful Packet Inspection (SPI) |
Yes |
| Filtering |
Yes |
| DMZ support |
Yes |
| Network address translation (NAT) |
Yes |
| Power |
| Power source type |
AC, DC |
| Output voltage |
12 V |
| Output current |
1.5 A |
| Weight & dimensions |
| Width |
214 mm |
| Depth |
144.5 mm |
| Height |
80 mm |
| System requirements |
| Windows operating systems supported |
Windows 10, Windows 2000, Windows 7, Windows 8, Windows 8.1, Windows 98SE, Windows NT, Windows Vista, Windows XP |
| Linux operating systems supported |
Yes |
| Mac operating systems supported |
Yes |
| Operational conditions |
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-40 - 70 °C |
| Operating relative humidity (H-H) |
10 - 90% |
| Storage relative humidity (H-H) |
5 - 90% |
| Design |
| Product type |
Portable router |
| Product colour |
Black |
| Wall mountable |
Yes |
| LED indicators |
LAN, Link, Power, Status, WAN |
| On/off switch |
Yes |
| Features |
| Firmware upgradeable |
Yes |
| WAN connection |
| Ethernet WAN |
Yes |
| DSL WAN |
Yes |
| SIM card slot |
No |
| 3G/4G USB modem compatibility |
Yes |
| WAN connection type |
RJ-45 |
| Packaging data |
| Package type |
Box |
| Packaging content |
| AC adapter included |
Yes |
| Manual |
Yes |
| Sustainability |
| Sustainability compliance |
Yes |
| Sustainability certificates |
CE, EAC, RoHS |
