Stock Status: 1x unit in stock
The Smarter Cloud Solution for Business Networking.
AX1800 Wall Plate WiFi 6 Access Point
Futureproof Your Network with WiFi 6 Connectivity
Connect more devices at the same time with WiFi 6 speeds of up to 1800 Mbps..
Corner-to-Corner Indoor WiFi Coverage
Guests can enjoy strong private networks that paint their entire space by installing EAP615-Walls in each guest room.
Specs
| Operational conditions |
| Operating relative humidity (H-H) |
10 - 90% |
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-40 - 70 °C |
| Storage relative humidity (H-H) |
5 - 90% |
| Weight & dimensions |
| Width |
143 mm |
| Depth |
86 mm |
| Height |
20 mm |
| Ports & interfaces |
| Ethernet LAN (RJ-45) ports |
4 |
| Power |
| Power over Ethernet (PoE) |
Y |
| Security |
| Security algorithms |
WPA,WPA2,WPA3 |
| Service Set Identifier (SSID) features |
Multiple SSIDs |
| Number of SSID supported |
16 |
| Remote Authentication Dial-In User Service (RADIUS) |
Y |
| Access Control List (ACL) |
Y |
| Protocols |
| STelnet using SSH v2 |
Y |
| Antenna |
| Antenna type |
Internal |
| Design |
| Placement |
Wall |
| Product colour |
White |
| On/off switch |
Y |
| Reset button |
Y |
| LED indicators |
Power |
| Certification |
CE, FCC, RoHS |
| Features |
| 2.4 GHz |
Y |
| 5 GHz |
Y |
| Maximum data transfer rate |
1774 Mbit/s |
| Maximum data transfer rate (2.4 GHz) |
574 Mbit/s |
| Maximum data transfer rate (5 GHz) |
1201 Mbit/s |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Networking standards |
IEEE 802.11a,IEEE 802.11ac,IEEE 802.11ax,IEEE 802.11b,IEEE 802.11g,IEEE 802.11n |
| Cabling technology |
10/100/1000Base-T(X) |
| Automatic channel selection |
Y |
| Automatic channel scanning |
Y |
| MIMO |
Y |
| MIMO type |
Multi User MIMO |
| VLAN support |
Y |
| Rate limiting |
Y |
| Band steering |
Y |
| Airtime Fairness (ATF) |
Y |
| Quality of Service (QoS) support |
Y |
| Transmitting power (CE) |
20 dBm |
| Transmitting power (FCC) |
21 dBm |
| Management features |
| Syslog |
Y |
Features
TP-Link AX1800 Wall Plate WiFi 6 Access Point. Maximum data transfer rate: 1774 Mbit/s, Maximum data transfer rate (2.4 GHz): 574 Mbit/s, Maximum data transfer rate (5 GHz): 1201 Mbit/s. Security algorithms: WPA,WPA2,WPA3, Service Set Identifier (SSID) features: Multiple SSIDs. Placement: Wall, Product colour: White, LED indicators: Power. Antenna type: Internal. Width: 143 mm, Depth: 86 mm, Height: 20 mm
Product Description
The Smarter Cloud Solution for Business Networking.
AX1800 Wall Plate WiFi 6 Access Point
Futureproof Your Network with WiFi 6 Connectivity
Connect more devices at the same time with WiFi 6 speeds of up to 1800 Mbps..
Corner-to-Corner Indoor WiFi Coverage
Guests can enjoy strong private networks that paint their entire space by installing EAP615-Walls in each guest room.
