| Design |
| Product colour |
White |
| Antenna type |
Internal |
| Product type |
Mesh router |
| LED indicators |
Yes |
| Antennas quantity |
4 |
| Maximum coverage |
270 m² |
| Transmit power |
FCC: <30 dBm (2.4 GHz), <30 dBm (5 GHz), <30 dBm (6 GHz), CE: <20 dBm (2.4 GHz), <23 dBm (5 GHz), <23 dBm (6 GHz) |
| Reset button |
Yes |
| Packaging content |
| Number of products included |
1 pc(s) |
| AC adapter included |
Yes |
| Number of units included |
1 pc(s) |
| Ethernet cable |
Yes |
| Power |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50 - 60 Hz |
| AC adapter output voltage |
12 V |
| Weight & dimensions |
| Width |
105 mm |
| Depth |
105 mm |
| Height |
169 mm |
| Wireless LAN features |
| Wi-Fi band |
Tri-band (2.4 GHz / 5 GHz / 6 GHz) |
| Top Wi-Fi standard |
Wi-Fi 6E (802.11ax) |
| Wi-Fi standards |
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax) |
| WLAN data transfer rate (first band) |
574 Mbit/s |
| WLAN data transfer rate (second band) |
2402 Mbit/s |
| WLAN data transfer rate (third band) |
2402 Mbit/s |
| Networking standards |
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Security algorithms |
WPA, WPA2-PSK, WPA3 |
| Number of guest networks (5 GHz) |
1 |
| Number of guest networks (2.4 GHz) |
1 |
| Point-to-point protocol over Ethernet (PPPoE) |
Yes |
| Dynamic IP |
Yes |
| Static IP |
Yes |
| Wireless Distribution System (WDS) bridge |
Yes |
| IGMP proxy |
Yes |
| IGMP snooping |
Yes |
| Tagged VLAN |
Yes |
| Dynamic DNS (DDNS) |
Yes |
| Guest access |
Yes |
| Apps supported |
TP-Link Deco |
| Protocols |
| Supported network protocols (IPv6) |
Y |
| Ports & interfaces |
| Ethernet LAN (RJ-45) ports |
3 |
| Ethernet WAN |
Yes |
| DC-in jack |
Yes |
| Features |
| Built-in processor |
Yes |
| Processor cores |
4 |
| Processor frequency |
1.7 GHz |
| Quality of Service (QoS) support |
Yes |
| Port forwarding |
Yes |
| Firewall security |
SPI Firewall |
| BeamForming |
Yes |
| DHCP client |
Yes |
| DHCP server |
Yes |
| Universal Plug and Play (UPnP) |
Yes |
| Parental control |
Yes |
| Parental control features |
Bedtime, Content filter, Custom profiles, Family time, Pause the Internet, Time controls, Time rewards, Weekly/monthly reports |
| MU-MIMO technology |
Yes |
| MIMO |
Yes |
| Certificates |
| Certification |
CE, FCC, RoHS |
| Operational conditions |
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-40 - 60 °C |
| Operating relative humidity (H-H) |
10 - 90% |
| Storage relative humidity (H-H) |
5 - 90% |
| Packaging data |
| Package width |
213.5 mm |
| Package depth |
241 mm |
| Package height |
124 mm |
| Package weight |
1.2 kg |
