| Wireless LAN features |
| Wi-Fi band |
Dual-band (2.4 GHz / 5 GHz) |
| Top Wi-Fi standard |
Wi-Fi 5 (802.11ac) |
| WLAN data transfer rate (max) |
433 Mbit/s |
| Wi-Fi standards |
802.11a, 802.11b, 802.11g, Wi-Fi 5 (802.11ac) |
| WLAN data transfer rate (first band) |
300 Mbit/s |
| WLAN data transfer rate (second band) |
433 Mbit/s |
| Ports & interfaces |
| Ethernet LAN (RJ-45) ports |
1 |
| USB port |
Yes |
| USB 2.0 ports quantity |
1 |
| Mobile networking |
| Mobile network generation |
4G |
| Networking |
| Ethernet LAN |
Yes |
| Ethernet LAN interface type |
Fast Ethernet |
| Ethernet LAN data rates |
10,100 Mbit/s |
| Cabling technology |
10/100Base-T(X) |
| Networking standards |
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u |
| Port forwarding |
Yes |
| Port triggering |
Yes |
| Dynamic DNS (DDNS) |
Yes |
| Number of guest networks (2.4 GHz) |
1 |
| Number of guest networks (5 GHz) |
1 |
| Built-in FTP server |
Yes |
| Media server |
Yes |
| VPN Passthrough |
Yes |
| VPN support |
PPTP, L2TP, IPSec |
| Receiver sensitivity |
11a 54M: -76dBm; 11ac VHT20 MCS8: -70dBm;
11ac VHT40 MCS9: -65.5dBm; 11ac VHT80 MCS9:
-61.5dBm
2.4GHz:
11g 54M: -76dBm11n; HT20 MCS7: -74dBm;
11n HT40 MCS7: -71dBm |
| Protocols |
| DHCP client |
Yes |
| DHCP server |
Yes |
| Universal Plug and Play (UPnP) |
Yes |
| Supported network protocols |
IPv4, IPv6 |
| Antenna |
| Antenna design |
Internal |
| Antennas quantity |
2 |
| Receive power |
11a 54M: -76dBm; 11ac VHT20 MCS8: -70dBm; 11ac VHT40 MCS9: -65.5dBm; 11ac VHT80 MCS9: -61.5dBm, 2.4GHz: 11g 54M: -76dBm11n; HT20 MCS7: -74dBm; 11n HT40 MCS7: -71dBm |
| Transmit power |
CE:<20dBm(2.4GHz), <23dBm(5GHz) |
| Management features |
| Quality of Service (QoS) support |
Yes |
| Reset button |
Yes |
| WPS push button |
Yes |
| Security |
| Security algorithms |
WEP, WPA, WPA2 |
| Firewall |
Yes |
| Firewall security |
SPI |
| Guest access |
Yes |
| Stateful Packet Inspection (SPI) |
Yes |
| DoS attack prevention |
Yes |
| Filtering |
Yes |
| IP address filtering |
Yes |
| URL filtering |
Yes |
| DMZ support |
Yes |
| Power |
| Power source type |
USB |
| Output voltage |
5 V |
| Output current |
2 A |
| Weight & dimensions |
| Width |
74 mm |
| Depth |
67 mm |
| Height |
22 mm |
| Weight |
56.7 g |
| System requirements |
| Windows operating systems supported |
Yes |
| Linux operating systems supported |
Yes |
| Mac operating systems supported |
Yes |
| Mac compatibility |
Yes |
| Operational conditions |
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-40 - 70 °C |
| Operating relative humidity (H-H) |
10 - 90% |
| Storage relative humidity (H-H) |
5 - 90% |
| Design |
| Product type |
Portable router |
| Product colour |
White |
| Features |
| Built-in processor |
Yes |
| Processor cores |
1 |
| WAN connection |
| Ethernet WAN |
Yes |
| DSL WAN |
No |
| SIM card slot |
No |
| 3G/4G USB modem compatibility |
Yes |
| WAN connection type |
RJ-45 |
| Logistics data |
| Harmonized System (HS) code |
85176990 |
| Packaging data |
| Package width |
110 mm |
| Package depth |
109 mm |
| Package height |
81.5 mm |
| Package weight |
300 g |
| Certification |
| Compliance certificates |
RoHS, Federal Communications Commission (FCC), CE |
| Packaging content |
| Cables included |
LAN (RJ-45) |
| AC adapter included |
Yes |
| Quick start guide |
Yes |
| Sustainability |
| Sustainability compliance |
Yes |
