| Networking |
| Maximum data transfer rate |
2000 Mbit/s |
| Networking standards |
IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x |
| Ethernet LAN |
Y |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Cabling technology |
10/100/1000BaseT(X) |
| Wake-on-LAN ready |
Y |
| Full duplex |
Y |
| Flow control support |
Y |
| Jumbo frames support |
Y |
| Supported network protocols |
CSMA/CD, TCP/IP |
| Ethernet interface type |
Gigabit Ethernet |
| Quality of Service (QoS) support |
Y |
| VLAN tagging |
Y |
| Maximum operating distance |
100 m |
| Auto MDIX IEEE |
Y |
| Auto-negotiation |
Y |
| System requirements |
| Windows operating systems supported |
Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows |
| Linux operating systems supported |
Y |
| Weight & dimensions |
| Width |
78.5 mm |
| Depth |
120.8 mm |
| Height |
21.5 mm |
| Ports & interfaces |
| Connectivity technology |
Wired |
| Host interface |
PCI Express |
| Interface |
Ethernet |
| Ethernet LAN (RJ-45) ports |
1 |
| Operational conditions |
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-40 - 70 °C |
| Operating relative humidity (H-H) |
10 - 90% |
| Storage relative humidity (H-H) |
5 - 90% |
| Other features |
| Supported data transfer rates |
10/100/1000 Mbps |
| Data transfer rate |
1 Gbit/s |
| Operating temperature (T-T) |
32 - 104 °F |
| Flow control support |
Y |
| Harmonized System (HS) code |
85176990 |
| Design |
| Internal |
Y |
| Recommended usage |
PC / Notebook |
| Product colour |
Green, Grey |
| Certification |
FCC, BSMI, VCCI |
| Component for |
PC |
| LED indicators |
Status |
| Logistics data |
| Harmonized System (HS) code |
85176990 |
| Packaging data |
| Package width |
160 mm |
| Package depth |
135 mm |
| Package height |
30 mm |
| Package weight |
100 g |
| Technical details |
| Sustainability certificates |
RoHS |
| Packaging content |
| Mounting brackets included |
Y |
| Resource CD |
Y |
| Quick installation guide |
Y |
| Sustainability |
| Sustainability certificates |
BSMI, CE, Federal Communications Commission (FCC), RoHS |
| Sustainability compliance |
Y |
