| Networking |
| Maximum data transfer rate |
867 Mbit/s |
| Networking standards |
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Wi-Fi |
Y |
| Wi-Fi band |
Dual-band (2.4 GHz / 5 GHz) |
| Frequency range |
2.4 - 5 GHz |
| Top Wi-Fi standard |
Wi-Fi 5 (802.11ac) |
| Wi-Fi standards |
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| WLAN data transfer rates supported |
11,54,300,400,867 Mbit/s |
| Security algorithms |
64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK |
| Modulation |
16-QAM, 64-QAM, 256-QAM, CCK, DBPSK, DQPSK, OFDM |
| MU-MIMO |
Y |
| System requirements |
| Windows operating systems supported |
Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows |
| Mac operating systems supported |
Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.9 Mavericks |
| Weight & dimensions |
| Width |
40.5 mm |
| Depth |
19.7 mm |
| Height |
10.3 mm |
| Ports & interfaces |
| Connectivity technology |
Wired |
| Host interface |
USB |
| Interface |
WLAN |
| USB version |
3.2 Gen 1 (3.1 Gen 1) |
| USB ports quantity |
1 |
| Operational conditions |
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-40 - 70 °C |
| Operating relative humidity (H-H) |
10 - 90% |
| Storage relative humidity (H-H) |
5 - 90% |
| Power |
| USB powered |
Y |
| Other features |
| Harmonized System (HS) code |
85176990 |
| Design |
| Internal |
N |
| Component for |
PC/notebook |
| Product colour |
Black |
| Antenna |
Y |
| Antenna design |
Internal |
| Transmitting power (CE) |
23 dBm |
| Transmitting power (FCC) |
23 dBm |
| LED indicators |
Status |
| Receiver sensitivity |
5GHz：
11a 6Mbps: -91dBm
11a 54Mbps: -76dBm
11n HT20：-71dBm
11n HT40：-70dBm
11ac HT20: -68dBm
11ac HT40: -64dBm
11ac HT80: -62dBm
2.4GHz:
11b 11Mbps: -86dBm
11g 54Mbps: -73dBm
11n HT20: -71dBm
11n HT40: -70dBm |
| Certification |
CE, FCC |
| Antenna direction type |
Omni-directional |
| Operating modes |
Infrastructure mode |
| Logistics data |
| Harmonized System (HS) code |
85176990 |
| Packaging content |
| Quick installation guide |
Y |
| Resource CD |
Y |
| Sustainability |
| Sustainability certificates |
CE, Federal Communications Commission (FCC), RoHS |
| Sustainability compliance |
Y |
