| Operational conditions |
| Operating relative humidity (H-H) |
10 - 90% |
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-40 - 70 °C |
| Storage relative humidity (H-H) |
5 - 90% |
| Weight & dimensions |
| Width |
86.8 mm |
| Depth |
30.2 mm |
| Height |
86.8 mm |
| Ports & interfaces |
| Ethernet LAN (RJ-45) ports |
2 |
| USB 2.0 ports quantity |
0 |
| Power |
| Power over Ethernet (PoE) |
Yes |
| Power consumption (typical) |
2.8 W |
| Security |
| Security algorithms |
802.1x RADIUS, HTTPS, WPA, WPA-PSK, WPA2, WPA2-PSK |
| MAC address filtering |
Yes |
| Number of SSID supported |
8 |
| Protocols |
| Management protocols |
SNMP, Telnet |
| Antenna |
| Antenna type |
Internal |
| Antennas quantity |
2 |
| Antenna gain level (max) |
1.8 dBi |
| Design |
| Placement |
Wall |
| Product colour |
White |
| Cable lock slot |
No |
| Reset button |
Yes |
| LED indicators |
Yes |
| Logistics data |
| Harmonized System (HS) code |
85176990 |
| Features |
| 2.4 GHz |
Yes |
| 5 GHz |
No |
| Maximum data transfer rate |
300 Mbit/s |
| Maximum data transfer rate (2.4 GHz) |
300 Mbit/s |
| Ethernet LAN data rates |
10,100 Mbit/s |
| Networking standards |
IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3af, IEEE 802.3u |
| Cabling technology |
10/100Base-T(X) |
| Automatic channel selection |
Yes |
| Wi-Fi Multimedia (WMM)/(WME) |
Yes |
| Rate limiting |
Yes |
| Wireless isolation |
Yes |
| Quality of Service (QoS) support |
Yes |
| Transmitting power |
15 dBmW |
| Management features |
| Web-based management |
Yes |
