| Operational conditions |
| Operating relative humidity (H-H) |
10 - 90% |
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-40 - 70 °C |
| Storage relative humidity (H-H) |
5 - 90% |
| Weight & dimensions |
| Width |
143 mm |
| Depth |
86 mm |
| Height |
20 mm |
| Ports & interfaces |
| Ethernet LAN (RJ-45) ports |
4 |
| WAN connection |
Ethernet (RJ-45) |
| Power |
| Power over Ethernet (PoE) |
Yes |
| Power over Ethernet (PoE) type supported |
Active PoE, Passive PoE |
| Power consumption (typical) |
24.4 W |
| Security |
| Security algorithms |
64-bit WEP, 128-bit WEP, 152-bit WEP, 802.1x RADIUS, HTTPS, SNMP, SNMPv3, SSH, WPA, WPA-Enterprise, WPA-PSK, WPA2, WPA2-Enterprise, WPA2-PSK |
| MAC address filtering |
Yes |
| Service Set Identifier (SSID) features |
Multiple SSIDs |
| Number of SSID supported |
16 |
| Remote Authentication Dial-In User Service (RADIUS) |
Yes |
| Access Control List (ACL) |
Yes |
| Protocols |
| Universal Plug and Play (UPnP) |
Yes |
| Antenna |
| Antenna type |
Internal |
| Antenna features |
Integrated antenna |
| Antennas quantity |
2 |
| Antenna gain level (max) |
4 dBi |
| Design |
| Placement |
Wall |
| Product colour |
White |
| Cable lock slot |
Yes |
| Reset button |
Yes |
| LED indicators |
LAN, Power, Status, WAN, WLAN |
| Performance |
| Compatible operating systems |
Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10 |
| Logistics data |
| Harmonized System (HS) code |
85176990 |
| Features |
| 2.4 GHz |
Yes |
| 5 GHz |
Yes |
| 6 GHz |
No |
| Maximum data transfer rate |
1167 Mbit/s |
| Maximum data transfer rate (2.4 GHz) |
300 Mbit/s |
| Maximum data transfer rate (5 GHz) |
867 Mbit/s |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Frequency band |
2.4 - 5 GHz |
| Networking standards |
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1x, IEEE 802.3af, IEEE 802.3at |
| Cabling technology |
10/100/1000Base-T(X) |
| Automatic channel selection |
Yes |
| Automatic channel scanning |
Yes |
| MIMO |
Yes |
| MIMO type |
Multi User MIMO |
| Wi-Fi Multimedia (WMM)/(WME) |
Yes |
| VLAN support |
Yes |
| Virtual LAN features |
Port-based VLAN, VLAN mapping |
| Rate limiting |
Yes |
| Wireless isolation |
Yes |
| Band steering |
Yes |
| Quality of Service (QoS) support |
Yes |
| BeamForming |
Yes |
| Transmitting power (CE) |
20 - 23 dBm |
| Transmitting power (FCC) |
21 dBm |
| Packaging data |
| Package width |
117 mm |
| Package depth |
184 mm |
| Package height |
33 mm |
| Package weight |
300 g |
| Package type |
Box |
| Management features |
| Web-based management |
Yes |
| Syslog |
Yes |
| Technical details |
| Compliance certificates |
CE, Federal Communications Commission (FCC), RoHS |
| Packaging content |
| Number of products included |
1 pc(s) |
| Mounting kit |
Yes |
| Quick start guide |
Yes |
| Sustainability |
| Sustainability compliance |
Yes |
