| Display |
| Display diagonal |
40.6 cm (16") |
| Display resolution |
1920 x 1200 pixels |
| Touchscreen |
No |
| HD type |
WUXGA |
| Panel type |
IPS |
| LED backlight |
Yes |
| Native aspect ratio |
16:10 |
| Anti-glare screen |
Yes |
| Display brightness |
500 cd/m² |
| RGB colour space |
sRGB |
| Colour gamut |
100% |
| Maximum refresh rate |
60 Hz |
| Processor |
| Processor family |
Intel Core Ultra 9 |
| Processor manufacturer |
Intel |
| Processor model |
275HX |
| Processor generation |
Intel Core Ultra (Series 2) |
| Processor cores |
24 |
| Processor threads |
24 |
| Processor boost frequency |
5.4 GHz |
| Performance cores |
8 |
| Efficient cores |
16 |
| Performance-core Max Turbo Frequency |
5.4 GHz |
| Efficient-core Max Turbo Frequency |
4.6 GHz |
| Performance-core base frequency |
2.7 GHz |
| Efficient-core base frequency |
2.1 GHz |
| Processor cache |
36 MB |
| Processor base power |
55 W |
| Maximum turbo power |
160 W |
| Processore |
| Processor family |
Intel Core Ultra 9 |
| Processor manufacturer |
Intel |
| Processor model |
275HX |
| Processor generation |
Intel Core Ultra (Series 2) |
| Processor cores |
24 |
| Processor threads |
24 |
| Processor boost frequency |
5.4 GHz |
| Performance cores |
8 |
| Efficient cores |
16 |
| Performance-core Max Turbo Frequency |
5.4 GHz |
| Efficient-core Max Turbo Frequency |
4.6 GHz |
| Performance-core base frequency |
2.7 GHz |
| Efficient-core base frequency |
2.1 GHz |
| Processor cache |
36 MB |
| Processor base power |
55 W |
| Maximum turbo power |
160 W |
| Connettività |
| USB 2.0 ports quantity |
0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity |
0 |
| HDMI ports quantity |
1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity |
2 |
| Ethernet LAN (RJ-45) ports |
1 |
| HDMI version |
2.1 |
| Thunderbolt 4 ports quantity |
1 |
| Thunderbolt 5 ports quantity |
2 |
| Intel® Thunderbolt 4 |
Yes |
| Intel® Thunderbolt 5 |
Yes |
| Combo headphone/mic port |
Yes |
| USB Sleep-and-Charge |
Yes |
| Ports & interfaces |
| USB 2.0 ports quantity |
0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity |
0 |
| HDMI ports quantity |
1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity |
2 |
| Ethernet LAN (RJ-45) ports |
1 |
| HDMI version |
2.1 |
| Thunderbolt 4 ports quantity |
1 |
| Thunderbolt 5 ports quantity |
2 |
| Intel® Thunderbolt 4 |
Yes |
| Intel® Thunderbolt 5 |
Yes |
| Combo headphone/mic port |
Yes |
| USB Sleep-and-Charge |
Yes |
| Memoria |
| Internal memory |
64 GB |
| Maximum internal memory |
128 GB |
| Internal memory type |
DDR5-SDRAM |
| Memory clock speed |
5600 MHz |
| Memory form factor |
SO-DIMM |
| Memory layout (slots x size) |
2 x 32 GB |
| Memory slots |
4x SO-DIMM |
| Memory |
| Internal memory |
64 GB |
| Maximum internal memory |
128 GB |
| Internal memory type |
DDR5-SDRAM |
| Memory clock speed |
5600 MHz |
| Memory form factor |
SO-DIMM |
| Memory layout (slots x size) |
2 x 32 GB |
| Memory slots |
4x SO-DIMM |
| Dimensioni e peso |
| Weight |
2.54 kg |
| Width |
362 mm |
| Depth |
252 mm |
| Height (front) |
1.58 cm |
| Height (rear) |
2.09 cm |
| Weight & dimensions |
| Weight |
2.54 kg |
| Width |
362 mm |
| Depth |
252 mm |
| Height (front) |
1.58 cm |
| Height (rear) |
2.09 cm |
| Gestione energetica |
| USB Type-C charging port |
Yes |
| AC adapter power |
180 W |
| AC adapter frequency |
50/60 Hz |
| AC adapter input voltage |
100 - 240 V |
| USB Power Delivery (USB PD) |
Yes |
| Power |
| USB Type-C charging port |
Yes |
| AC adapter power |
180 W |
| AC adapter frequency |
50/60 Hz |
| AC adapter input voltage |
100 - 240 V |
| USB Power Delivery (USB PD) |
Yes |
| Audio |
| Number of built-in speakers |
2 |
| Speaker power |
2 W |
| Built-in microphone |
Yes |
| Number of microphones |
2 |
| Keyboard |
| Numeric keypad |
Yes |
| Pointing device |
ThinkPad UltraNav |
| Keyboard backlit |
Yes |
| Keyboard language |
English |
| Tastiera |
| Numeric keypad |
Yes |
| Pointing device |
ThinkPad UltraNav |
| Keyboard backlit |
Yes |
| Keyboard language |
English |
| Condizioni ambientali |
| Operating temperature (T-T) |
5 - 35 °C |
| Storage temperature (T-T) |
5 - 43 °C |
| Operating relative humidity (H-H) |
8 - 95% |
| Storage relative humidity (H-H) |
5 - 95% |
| Operational conditions |
| Operating temperature (T-T) |
5 - 35 °C |
| Storage temperature (T-T) |
5 - 43 °C |
| Operating relative humidity (H-H) |
8 - 95% |
| Storage relative humidity (H-H) |
5 - 95% |
| Collegamento in rete |
| Mobile network connection |
No |
| Top Wi-Fi standard |
Wi-Fi 7 (802.11be) |
| Wi-Fi standards |
Wi-Fi 7 (802.11be) |
| Antenna type |
2x2 |
| WLAN controller manufacturer |
Intel |
| Ethernet LAN |
Yes |
| Bluetooth |
Yes |
| Bluetooth version |
5.4 |
| Near Field Communication (NFC) |
No |
| WWAN |
Not installed |
| Networking |
| Mobile network connection |
No |
| Top Wi-Fi standard |
Wi-Fi 7 (802.11be) |
| Wi-Fi standards |
Wi-Fi 7 (802.11be) |
| Antenna type |
2x2 |
| WLAN controller manufacturer |
Intel |
| Ethernet LAN |
Yes |
| Bluetooth |
Yes |
| Bluetooth version |
5.4 |
| Near Field Communication (NFC) |
No |
| WWAN |
Not installed |
| Security |
| Cable lock slot |
Yes |
| Cable lock slot type |
Kensington |
| Fingerprint reader |
Yes |
| Smart card reader |
No |
| Trusted Platform Module (TPM) |
Yes |
| Trusted Platform Module (TPM) version |
2.0 |
| Sicurezza |
| Cable lock slot |
Yes |
| Cable lock slot type |
Kensington |
| Fingerprint reader |
Yes |
| Smart card reader |
No |
| Trusted Platform Module (TPM) |
Yes |
| Trusted Platform Module (TPM) version |
2.0 |
| Certificates |
| Certification |
ENERGY STAR,TCO,EPEAT Gold,RoHS |
| Certificati di sicurezza |
| Certification |
ENERGY STAR,TCO,EPEAT Gold,RoHS |
| Operating system/software |
| Operating system installed |
Windows 11 Pro |
| Operating system architecture |
64-bit |
| Bundled software |
Lenovo AI Now |
| Software |
| Operating system installed |
Windows 11 Pro |
| Operating system architecture |
64-bit |
| Bundled software |
Lenovo AI Now |
| Camera |
| Front camera resolution (numeric) |
5 MP |
| Infrared (IR) camera |
Yes |
| Privacy camera |
Yes |
| Privacy type |
Privacy shutter |
| Macchina fotografica |
| Front camera resolution (numeric) |
5 MP |
| Infrared (IR) camera |
Yes |
| Privacy camera |
Yes |
| Privacy type |
Privacy shutter |
| Archiviazione |
| Total storage capacity |
1 TB |
| Storage media |
SSD |
| Optical drive type |
No |
| Total SSDs capacity |
1 TB |
| Number of SSDs installed |
1 |
| SSD capacity |
1 TB |
| SSD interface |
PCI Express 5.0 |
| NVMe |
Yes |
| SSD form factor |
M.2 |
| Card reader integrated |
Yes |
| Compatible memory cards |
SD |
| Storage |
| Total storage capacity |
1 TB |
| Storage media |
SSD |
| Optical drive type |
No |
| Total SSDs capacity |
1 TB |
| Number of SSDs installed |
1 |
| SSD capacity |
1 TB |
| SSD interface |
PCI Express 5.0 |
| NVMe |
Yes |
| SSD form factor |
M.2 |
| Card reader integrated |
Yes |
| Compatible memory cards |
SD |
| Batteria |
| Battery capacity |
99.9 Wh |
| Battery technology |
Lithium-Ion (Li-Ion) |
| Battery |
| Battery capacity |
99.9 Wh |
| Battery technology |
Lithium-Ion (Li-Ion) |
| Grafica |
| On-board graphics card |
Yes |
| Discrete graphics card |
Yes |
| Discrete graphics card model |
NVIDIA RTX PRO 4000 Blackwell |
| On-board graphics card model |
Intel Graphics |
| Discrete GPU manufacturer |
NVIDIA |
| Discrete graphics card memory |
16 GB |
| Discrete graphics memory type |
GDDR7 |
| On-board GPU manufacturer |
Intel |
| On-board graphics card family |
Intel Graphics |
| Graphics |
| On-board graphics card |
Yes |
| Discrete graphics card |
Yes |
| Discrete graphics card model |
NVIDIA RTX PRO 4000 Blackwell |
| On-board graphics card model |
Intel Graphics |
| Discrete GPU manufacturer |
NVIDIA |
| Discrete graphics card memory |
16 GB |
| Discrete graphics memory type |
GDDR7 |
| On-board GPU manufacturer |
Intel |
| On-board graphics card family |
Intel Graphics |
| Design |
| Product type |
Laptop |
| Product colour |
Black |
| Form factor |
Clamshell |
| Housing material |
Aluminium |
| Performance |
| Motherboard chipset |
Intel WM880 |
| Prestazione |
| Motherboard chipset |
Intel WM880 |
| Contenuto dell'imballo |
| AC adapter included |
Yes |
| Packaging content |
| AC adapter included |
Yes |
| Neural processor unit (NPU) |
| Neural processor unit (NPU) |
Intel AI Boost |
| Sparsity support |
Yes |
| Windows Studio effects support |
Yes |
| AI software frameworks supported by NPU |
DirectML, OpenVINO, Windows ML, ONNX RT, WebNN |
| Total processor performance up to |
36 TOPs |
| NPU performance up to |
13 TOPs |
| GPU performance up to |
8 TOPs |
