Stock Status: 1x unit in stock
This DOCKTB4PT Thunderbolt 4 Triple Alt Mode Display Docking Station from V7 adds up to 3 displays, 3 USB ports, 2 Thunderbolt 4 ports, a USB-C port with up to 96 Watts Power Delivery, Audio, SD/Micro SD Memory Cards and up to 2.5 Gigabit Ethernet network connectivity to your Thunderbolt 4 enabled computer while charging at the same time with up to 96W power delivery. It features two HDMI ports and two DisplayPort outputs that can be used to extend or mirror your device for multitasking productivity. It supports single 8K 30Hz display (HDMI or DP) or up to three 4K (4K/60Hz + 4K/60Hz + 4K/30Hz) displays. It is Thunderbolt 4 certified and compatible with DisplayPort Alt mode and USB4 enabled computers and mobile devices. It includes both K-Lock and N-Lock interface for security. This solution provides high performance connectivity to extend and enhance your workstation productivity with a 2 year warranty.
Specs
| Weight & dimensions |
| Width |
85 mm |
| Depth |
225 mm |
| Height |
22 mm |
| Weight |
500 g |
| Ports & interfaces |
| Connectivity technology |
Wired |
| Host interface |
Thunderbolt 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
1 |
| HDMI ports quantity |
2 |
| Microphone in |
Yes |
| Headphone outputs |
1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity |
2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity |
1 |
| DisplayPorts quantity |
2 |
| Thunderbolt 4 ports quantity |
3 |
| Combo headphone/mic port |
Yes |
| Headphone connectivity |
3.5 mm |
| Power |
| Power source type |
DC |
| AC input voltage |
100 - 240 V |
| Output voltage |
20 V |
| Output current |
7.5 A |
| Packaging content |
| Cables included |
DC |
| AC adapter included |
Yes |
| Quick start guide |
Yes |
| Operational conditions |
| Operating temperature (T-T) |
0 - 45 °C |
| Storage temperature (T-T) |
0 - 70 °C |
| Networking |
| Ethernet LAN |
Yes |
| Ethernet LAN (RJ-45) ports |
1 |
| Performance |
| Product colour |
Black, Silver |
| Card reader integrated |
Yes |
| Compatible memory cards |
MicroSD (TransFlash), SD |
| Data transfer rate |
2.5 Gbit/s |
| HD type |
4K Ultra HD |
| Cable lock slot |
Yes |
| Cable lock slot type |
Kensington |
| On/off switch |
Yes |
| LED indicators |
Yes |
| Housing material |
Acrylonitrile butadiene styrene (ABS) |
| Country of origin |
Vietnam |
| Certification |
CE,FCC,RoHS |
| Packaging data |
| Quantity per pack |
1 pc(s) |
| Package width |
160 mm |
| Package depth |
270 mm |
| Package height |
60 mm |
| Package weight |
1.05 kg |
Features
V7 DOCKTB4PT. Connectivity technology: Wired, Host interface: Thunderbolt 4, Headphone connectivity: 3.5 mm. Product colour: Black, Silver, Compatible memory cards: MicroSD (TransFlash), SD, Data transfer rate: 2.5 Gbit/s. Power source type: DC, AC input voltage: 100 - 240 V, Output voltage: 20 V. Width: 85 mm, Depth: 225 mm, Height: 22 mm. Quantity per pack: 1 pc(s), Package width: 160 mm, Package depth: 270 mm
Product Description
This DOCKTB4PT Thunderbolt 4 Triple Alt Mode Display Docking Station from V7 adds up to 3 displays, 3 USB ports, 2 Thunderbolt 4 ports, a USB-C port with up to 96 Watts Power Delivery, Audio, SD/Micro SD Memory Cards and up to 2.5 Gigabit Ethernet network connectivity to your Thunderbolt 4 enabled computer while charging at the same time with up to 96W power delivery. It features two HDMI ports and two DisplayPort outputs that can be used to extend or mirror your device for multitasking productivity. It supports single 8K 30Hz display (HDMI or DP) or up to three 4K (4K/60Hz + 4K/60Hz + 4K/30Hz) displays. It is Thunderbolt 4 certified and compatible with DisplayPort Alt mode and USB4 enabled computers and mobile devices. It includes both K-Lock and N-Lock interface for security. This solution provides high performance connectivity to extend and enhance your workstation productivity with a 2 year warranty.
