| System requirements |
| Windows operating systems supported |
Windows 10, Windows 11, Windows 7, Windows 8 |
| Mac operating systems supported |
Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10 |
| Linux operating systems supported |
Yes |
| Other operating systems supported |
Android |
| Operational conditions |
| Minimum operating temperature |
0 °C |
| Maximum operating temperature |
40 °C |
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-20 - 70 °C |
| Operating relative humidity (H-H) |
10 - 85% |
| Power |
| Power supply type |
USB |
| Input voltage |
5 - 20 V |
| Output voltage |
5 V |
| Output current |
0.9 A |
| Weight & dimensions |
| Width |
29.7 mm |
| Depth |
123.2 mm |
| Height |
11 mm |
| Weight |
60 g |
| Ports & interfaces |
| Ports quantity |
7 |
| Host interface |
USB 3.2 Gen 1 (3.1 Gen 1) Type-C |
| Hub interfaces |
HDMI, USB 3.2 Gen 1 (3.1 Gen 1) Type-A, USB 3.2 Gen 1 (3.1 Gen 1) Type-C |
| USB 2.0 Type-C ports quantity |
1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity |
1 |
| HDMI ports quantity |
1 |
| Card reader integrated |
Yes |
| Card reader slot |
2 |
| Compatible memory cards |
MicroSD (TransFlash), MicroSDHC, MicroSDXC, SD, SDHC, SDXC |
| Packaging content |
| Quick start guide |
Yes |
| Technical details |
| Pallet net height |
12 cm |
| Pallet net length |
120 cm |
| Pallet net width |
100 cm |
| Pallet net weight |
12 kg |
| Compliance certificates |
CE, Electromagnetic Compatibility (EMC), Federal Communications Commission (FCC), Low Voltage Directive (LVD), REACH, RoHS, UKCA |
| Logistics data |
| Pallet gross width |
100 cm |
| Pallet gross length |
120 cm |
| Pallet gross height |
120 cm |
| Pallet gross weight |
270 kg |
| Master (outer) case width |
256 mm |
| Master (outer) case length |
345 mm |
| Master (outer) case height |
236 mm |
| Master (outer) case gross weight |
5.7 kg |
| Packaging data |
| Quantity per pack |
1 pc(s) |
| Package width |
85 mm |
| Package depth |
155 mm |
| Package height |
20 mm |
| Package weight |
110 g |
| Package type |
Box |
| Features |
| Data transfer rate |
5000 Mbit/s |
| Supported graphics resolutions |
3840 x 2160 |
| Maximum resolution (HDMI) |
3840 x 2160 pixels |
| Product colour |
Grey |
| Housing material |
Acrylonitrile butadiene styrene (ABS), Aluminium |
| USB Power Delivery (USB PD) |
Yes |
| USB Power Delivery revision |
3.0 |
| USB Power Delivery up to |
100 W |
| HD type |
4K Ultra HD |
| Number of displays supported |
1 |
| Cable type |
Round cable |
| Cable length |
0.15 m |
| Plug and Play |
Yes |
| Country of origin |
China |
