Stock Status: 1x unit in stock
The Vertiv Liebert GXT5-EBC192VRT3U is an external hot-swappable, lead-acid UPS battery cabinet designed for use with these UPS models: Liebert GXT5-5000IRT5UXLE , Liebert GXT5-6000IRT5UXLE, Liebert GXT5-8000IRT5UXLE, and Liebert GXT5-10KIRT5UXLE. Its new auto detection feature makes installation easy and fast ensuring the UPS configuration is complete and accurate. Users can connect to up to 10 external battery cabinets to a single UPS for extended runtime
Specs
| Weight & dimensions |
| Width |
430 mm |
| Depth |
581 mm |
| Height |
173 mm |
| Weight |
65 kg |
| Package width |
670 mm |
| Package depth |
840 mm |
| Package height |
465 mm |
| Operational conditions |
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-15 - 40 °C |
| Operating relative humidity (H-H) |
0 - 95% |
| Storage relative humidity (H-H) |
0 - 95% |
| Operating altitude |
0 - 3000 m |
| Other features |
| Output voltage |
230 V |
| Battery |
| Battery technology |
Sealed Lead Acid (VRLA) |
| Battery capacity |
9 Ah |
| Number of batteries supported |
16 |
| Design |
| International Protection (IP) code |
IP20 |
| Safety |
IEC62040-1:2008 |
| Features |
| Number of output phases |
1 |
| Overload capacity (5 minute) |
125% |
| Overload capacity (1 minute) |
150% |
| Noise level |
55 dB |
| Power protection features |
Overload |
| Logistics data |
| Harmonized System (HS) code |
85078000 |
Features
Vertiv Liebert GXT5 / 5 - 10 KVA External battery cabinet. Overload capacity (5 minute): 125%, Overload capacity (1 minute): 150%, Noise level: 55 dB. Battery technology: Sealed Lead Acid (VRLA), Battery capacity: 9 Ah. International Protection (IP) code: IP20, Safety: IEC62040-1:2008. Width: 430 mm, Depth: 581 mm, Height: 173 mm. Output voltage: 230 V
Product Description
The Vertiv Liebert GXT5-EBC192VRT3U is an external hot-swappable, lead-acid UPS battery cabinet designed for use with these UPS models: Liebert GXT5-5000IRT5UXLE , Liebert GXT5-6000IRT5UXLE, Liebert GXT5-8000IRT5UXLE, and Liebert GXT5-10KIRT5UXLE. Its new auto detection feature makes installation easy and fast ensuring the UPS configuration is complete and accurate. Users can connect to up to 10 external battery cabinets to a single UPS for extended runtime
