Stock Status: 1x unit in stock
The Vertiv Liebert GXT5 UPS 3000VA/3000W, is a 2U UPS solution for ensuring the health and availability of IT infrastructure. With online, double conversion technology, the UPS protects critical equipment against outages and every type of power disturbance without drawing on battery power, extending battery life and minimizing replacements. This can support a wide range of power environment including 200/208/220/230/240V user configurable AC power and has scalable runtime options with matching external battery cabinets to offer extra time during an outage to support critical equipment and activity. This unit has a built-in Vertiv RDU101 communications card for remote monitoring to help you make more informed decisions and faster event resolution. It includes hot-swappable batteries and all hardware for installing it as a tower or in an equipment rack. This single-phase UPS is ENERGY STAR® 2.0 certified and offers leading normal mode power efficiency and Eco-mode for ultimate efficiency levels. It has a three-year factory warranty. It offers premium power protection for critical infrastructure in centralized and edge applications. It comes with a 5-year warranty (3-year factory warranty plus 2-year extended warranty). This promotion is subject to the Distributor’s product availability and is only available while product stocks last. Vertiv reserves the right to provide a 1-month notice to terminate the offer. This offer is not available in conjunction with any other offer/discount.
Specs
| Weight & dimensions |
| Width |
430 mm |
| Depth |
540 mm |
| Height |
85 mm |
| Weight |
28.5 kg |
| Operational conditions |
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-15 - 40 °C |
| Operating relative humidity (H-H) |
0 - 95% |
| Storage relative humidity (H-H) |
0 - 95% |
| Operating altitude |
0 - 3000 m |
| Ports & interfaces |
| AC outlet types |
C13 coupler, C19 coupler |
| Power plug |
C20 coupler |
| AC outlets quantity |
7 AC outlet(s) |
| USB port |
Yes |
| USB 2.0 ports quantity |
1 |
| USB port type |
USB Type-B |
| Modem (RJ-11) ports |
1 |
| Ethernet LAN (RJ-45) ports |
1 |
| Battery |
| Battery technology |
Sealed Lead Acid (VRLA) |
| Battery capacity |
9 Ah |
| Battery voltage |
12 V |
| Number of batteries included |
6 pc(s) |
| Typical backup time at full load |
3.3 min |
| Typical backup time at half load |
10.8 min |
| Battery recharge time |
3 h |
| Hot-swap battery |
Yes |
| Design |
| Form factor |
Rackmount/Tower |
| Product colour |
Black |
| Rack capacity |
2U |
| Control type |
Buttons |
| Display type |
LCD |
| LED indicators |
Yes |
| Features |
| UPS topology |
Double-conversion (Online) |
| Output power capacity |
3 kVA |
| Output power |
3000 W |
| Waveform |
Pure sine |
| Input operation voltage (min) |
115 V |
| Input operation voltage (max) |
288 V |
| Input frequency |
40 - 70 Hz |
| Output operation voltage (min) |
200 V |
| Output operation voltage (max) |
240 V |
| Output voltage regulation |
±3% |
| Efficiency |
95% |
| Power factor |
1 |
| ECO mode |
Yes |
| Noise level |
48 dB |
| Surge protection |
Yes |
| Audible alarm(s) |
Yes |
| Logistics data |
| Country of origin |
China |
| Packaging data |
| Package width |
717 mm |
| Package depth |
570 mm |
| Package height |
262 mm |
| Package weight |
33.4 kg |
| Certification |
| Compliance certificates |
REACH, RoHS, WEEE |
| Packaging content |
| Cables included |
USB cable |
| Manual |
Yes |
| Quick installation guide |
Yes |
| Safety regulation & standards |
| Safety |
EN 62040-1:2008+A1:2013 |
| Sustainability |
| Sustainability certificates |
ENERGY STAR |
| Sustainability compliance |
Yes |
Features
Vertiv Liebert GXT5 Double Online Conversion UPS -3000VA/3000W| 230V| With Rackmount Kit and Intellislot RDU101 Communication Card| GXT5-3000IRT2UXLN. UPS topology: Double-conversion (Online), Output power capacity: 3 kVA, Output power: 3000 W. AC outlet types: C13 coupler, C19 coupler, Power plug: C20 coupler, AC outlets quantity: 7 AC outlet(s). Battery technology: Sealed Lead Acid (VRLA), Battery capacity: 9 Ah, Battery voltage: 12 V. Form factor: Rackmount/Tower, Product colour: Black, Rack capacity: 2U. Compliance certificates: REACH, RoHS, WEEE
Product Description
The Vertiv Liebert GXT5 UPS 3000VA/3000W, is a 2U UPS solution for ensuring the health and availability of IT infrastructure. With online, double conversion technology, the UPS protects critical equipment against outages and every type of power disturbance without drawing on battery power, extending battery life and minimizing replacements. This can support a wide range of power environment including 200/208/220/230/240V user configurable AC power and has scalable runtime options with matching external battery cabinets to offer extra time during an outage to support critical equipment and activity. This unit has a built-in Vertiv RDU101 communications card for remote monitoring to help you make more informed decisions and faster event resolution. It includes hot-swappable batteries and all hardware for installing it as a tower or in an equipment rack. This single-phase UPS is ENERGY STAR® 2.0 certified and offers leading normal mode power efficiency and Eco-mode for ultimate efficiency levels. It has a three-year factory warranty. It offers premium power protection for critical infrastructure in centralized and edge applications. It comes with a 5-year warranty (3-year factory warranty plus 2-year extended warranty). This promotion is subject to the Distributor’s product availability and is only available while product stocks last. Vertiv reserves the right to provide a 1-month notice to terminate the offer. This offer is not available in conjunction with any other offer/discount.
