| Processor |
| Processor manufacturer |
Intel |
| Processor family |
Intel Atom® |
| Processor model |
Z530 |
| Processor frequency |
1.6 GHz |
| Processor cores |
1 |
| Processor threads |
2 |
| Processor cache |
0.512 MB |
| Processor front side bus |
533 MHz |
| Bus type |
FSB |
| Conflict-Free processor |
N |
| CPU multiplier (bus/core ratio) |
12 |
| FSB Parity |
N |
| Processing Die size |
26 mm² |
| Processor cache type |
L2 |
| Processor code |
SLB6P |
| Processor codename |
Silverthorne |
| Processor lithography |
45 nm |
| Processor operating modes |
32-bit |
| Processor package size |
13 x 14 mm |
| Scenario Design Power (SDP) |
0.96 W |
| Stepping |
C0 |
| Supported instruction sets |
SSE2, SSE3, SSSE3 |
| Tjunction |
90 °C |
| Thermal Design Power (TDP) |
2 W |
| Thermal Monitoring Technologies |
Y |
| Number of Processing Die Transistors |
47 M |
| Memory |
| Internal memory |
1 GB |
| Internal memory type |
DDR2-SDRAM |
| Display |
| Display diagonal |
20.3 cm (8") |
| Display resolution |
800 x 480 pixels |
| LED backlight |
Y |
| Touchscreen type |
Resistive |
| Audio |
| Built-in speaker(s) |
Y |
| Built-in microphone |
Y |
| Number of built-in speakers |
2 |
| Ports & interfaces |
| USB 2.0 ports quantity |
1 |
| Mobile High-Definition Link (MHL) |
N |
| Serial ports quantity |
2 |
| Microphone in |
N |
| Headphone out |
Y |
| DC-in jack |
Y |
| Weight & dimensions |
| Width |
268 mm |
| Depth |
43 mm |
| Height |
214 mm |
| Weight |
2.1 kg |
| Operational conditions |
| Operating temperature (T-T) |
-30 - 50 °C |
| Storage temperature (T-T) |
-30 - 60 °C |
| Operating relative humidity (H-H) |
5 - 95% |
| Storage relative humidity (H-H) |
5 - 95% |
| Networking |
| Top Wi-Fi standard |
802.11g |
| Bluetooth |
Y |
| Bluetooth version |
2.0+EDR |
| Wi-Fi standards |
802.11a, 802.11b, 802.11g |
| WWAN |
Upgradable |
| Storage |
| Internal storage capacity |
1 GB |
| Card reader integrated |
Y |
| Storage media |
Flash |
| Compatible memory cards |
SD |
| Camera |
| Front camera |
N |
| Rear camera |
N |
| Video recording |
N |
| Packaging content |
| Keyboard included |
N |
| Quick start guide |
Y |
| Other features |
| Keyboard layout |
QWERTY |
| Keyboard number of keys |
64 |
| Processor socket |
PBGA441 |
| Wi-Fi |
Y |
| Dustproof |
Y |
| Waterproof |
Y |
| Intel® Virtualization Technology (Intel® VT) |
VT-x |
| Processor ARK ID |
35463 |
| Harmonized System (HS) code |
84713000 |
| Battery |
| Battery technology |
Lithium-Ion (Li-Ion) |
| Graphics |
| Graphics adapter family |
Intel |
| Graphics adapter |
GMA 500 |
| Graphics card family |
Intel |
| Graphics card |
GMA 500 |
| Processor special features |
| Intel® Turbo Boost Technology |
N |
| Intel® Hyper Threading Technology (Intel® HT Technology) |
Y |
| Enhanced Intel SpeedStep Technology |
Y |
| Embedded options available |
Y |
| Execute Disable Bit |
Y |
| Idle States |
Y |
| Intel 64 |
N |
| Intel Enhanced Halt State |
Y |
| Intel Trusted Execution Technology |
N |
| Intel Virtualization Technology (VT-x) |
Y |
| Intel Virtualization Technology for Directed I/O (VT-d) |
N |
| Intel Demand Based Switching |
Y |
| Design |
| Form factor |
Slate |
| Product colour |
Black, Grey |
| Device type |
Mini tablet |
| Protection features |
Dust resistant, Scratch resistant, Shock resistant, Water resistant |
| Performance |
| Position location |
N |
| GPS (satellite) |
N |
| Operating system/software |
| Operating system version |
6.0 |
| Bundled software |
DCWedge |
| Platform |
Windows |
| Operating system installed |
Windows CE |
| Software |
| Operating system version |
6.0 |
| Bundled software |
DCWedge |
| Platform |
Windows |
| Operating system installed |
Windows CE |
| Features |
| Images Type Map |
|
| Logistics data |
| Harmonized System (HS) code |
84713000 |
