| Weight & dimensions |
| Height |
80 mm |
| Memory |
| Supported memory types |
DDR4-SDRAM |
| Number of memory slots |
4 |
| Maximum internal memory |
128 GB |
| Memory slots type |
DIMM |
| Memory channels |
Dual-channel |
| ECC |
Y |
| Non-ECC |
Y |
| Supported memory clock speeds |
2133,2400,2667,2933,3200,3400,3466,3600,3733,3866,4000,4133,4266,4400,4600,4800,5100 MHz |
| Unbuffered memory |
Y |
| Processor |
| Processor manufacturer |
AMD |
| Processor socket |
Socket AM4 |
| Compatible processor series |
AMD Ryzen™ 3, AMD Ryzen™ 5 |
| Supported processor sockets |
Socket AM4 |
| Back panel I/O ports |
| USB 2.0 ports quantity |
2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
4 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity |
1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity |
1 |
| Ethernet LAN (RJ-45) ports |
1 |
| HDMI ports quantity |
1 |
| PS/2 ports quantity |
1 |
| USB connector type |
USB Type-A, USB Type-C |
| Internal I/O |
| USB 2.0 connectors |
2 |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors |
1 |
| USB 3.2 Gen 2 (3.1 Gen 2) connectors |
1 |
| Number of SATA III connectors |
6 |
| Total number of SATA connectors |
6 |
| Front panel audio connector |
Y |
| Front panel connector |
Y |
| ATX Power connector (24-pin) |
Y |
| CPU fan connector |
Y |
| TPM connector |
Y |
| 12V power connector |
Y |
| RGB LED pin header |
Y |
| Networking |
| Ethernet LAN |
Y |
| Ethernet interface type |
2.5 Gigabit Ethernet |
| Expansion slots |
| PCI Express x1 slots |
2 |
| PCI Express x16 slots |
2 |
| Number of M.2 (M) slots |
3 |
| Packaging content |
| Bundled software |
Norton® Internet Security (OEM version)
Realtek® 8125 Gaming LAN Bandwidth Control Utility |
| BIOS |
| BIOS type |
UEFI AMI |
| BIOS memory size |
256 Mbit |
| ACPI version |
5.0 |
| Clear CMOS jumper |
Y |
| Desktop Management Interface (DMI) version |
2.7 |
| System Management BIOS (SMBIOS) version |
2.7 |
| Other features |
| Weight |
1 kg |
| Graphics |
| Maximum resolution |
4096 x 2160 pixels |
| HDCP |
Y |
| Features |
| Component for |
PC |
| Motherboard form factor |
ATX |
| Motherboard chipset family |
AMD |
| Motherboard chipset |
AMD X570 |
| Audio output channels |
7.1 channels |
| PC health monitoring |
Fan, Temperature, Voltage |
| Cooling type |
Active |
| Windows operating systems supported |
Windows 10 x64 |
| Storage controllers |
| Supported storage drive interfaces |
M.2, SATA III |
| Supported storage drive types |
HDD & SSD |
| RAID support |
Y |
| RAID levels |
0, 1, 10 |
