| Processor |
| Processor family |
Intel Core Ultra 5 |
| Processor manufacturer |
Intel |
| Processor model |
125H |
| Processor generation |
Intel® Core™ Ultra (Series 1) |
| Processor cores |
14 |
| Processor threads |
18 |
| Processor boost frequency |
4.5 GHz |
| Performance cores |
4 |
| Efficient cores |
8 |
| Low Power Efficient-cores |
2 |
| Performance-core Max Turbo Frequency |
4.5 GHz |
| Efficient-core Max Turbo Frequency |
3.6 GHz |
| Low Power Efficient-core Max Turbo Frequency |
2.5 GHz |
| Performance-core base frequency |
1.2 GHz |
| Efficient-core base frequency |
0.7 GHz |
| Low Power Efficient-core Base Frequency |
700 MHz |
| Processor cache |
18 MB |
| Processor cache type |
Smart Cache |
| Number of processors installed |
1 |
| Processor base power |
28 W |
| Maximum turbo power |
115 W |
| Memory |
| Internal memory |
16 GB |
| Internal memory type |
DDR5-SDRAM |
| Ports & interfaces |
| USB 2.0 ports quantity |
0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity |
0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity |
0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity |
0 |
| Thunderbolt 3 ports quantity |
0 |
| HDMI ports quantity |
4 |
| HDMI version |
2.0/2.1 |
| Ethernet LAN (RJ-45) ports |
1 |
| Headphone outputs |
1 |
| Weight & dimensions |
| Width |
188 mm |
| Depth |
188 mm |
| Height |
47.5 mm |
| Weight |
1.9 kg |
| Networking |
| Ethernet LAN |
Yes |
| Wi-Fi |
Yes |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Top Wi-Fi standard |
Wi-Fi 6 (802.11ax) |
| Wi-Fi standards |
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
| Bluetooth |
Yes |
| Bluetooth version |
5.2 |
| Operating system/software |
| Operating system installed |
Windows 11 IoT Enterprise |
| Operating system architecture |
64-bit |
| Software |
| Operating system installed |
Windows 11 IoT Enterprise |
| Operating system architecture |
64-bit |
| Storage |
| Total storage capacity |
256 GB |
| Optical drive type |
No |
| Storage media |
SSD |
| Total SSDs capacity |
256 GB |
| Graphics |
| Discrete graphics card |
No |
| On-board graphics card |
Yes |
| Discrete graphics card model |
Not available |
| On-board graphics card model |
Intel Arc Graphics |
| On-board GPU manufacturer |
Intel |
| On-board graphics card family |
Intel Arc Graphics |
| Design |
| Chassis type |
Mini PC |
| Product colour |
Black |
| Country of origin |
China |
| Performance |
| Product type |
PC |
| Trusted Platform Module (TPM) |
Yes |
| Trusted Platform Module (TPM) version |
2.0 |
| Packaging data |
| Package width |
371 mm |
| Package depth |
268 mm |
| Package height |
122 mm |
| Package weight |
12.3 kg |
| Neural processor unit (NPU) |
| Neural processor unit (NPU) |
Intel AI Boost |
| Sparsity support |
Yes |
| Windows Studio effects support |
Yes |
| AI software frameworks supported by NPU |
DirectML, ONNX RT, OpenVINO, Windows ML |
| Display |
| Display included |
No |
