| Ports & interfaces |
| Basic switching RJ-45 Ethernet ports quantity |
16 |
| Basic switching RJ-45 Ethernet ports type |
Gigabit Ethernet (10/100/1000) |
| Installed SFP modules quantity |
0 |
| Installed SFP+ modules quantity |
0 |
| Gigabit Ethernet (copper) ports quantity |
16 |
| Combo SFP ports quantity |
4 |
| Networking |
| Networking standards |
IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.1p, IEEE 802.3ad, IEEE 802.1x, IEEE 802.3at |
| 10G support |
No |
| Copper ethernet cabling technology |
10BASE-T, 100BASE-T, 1000BASE-T |
| Full duplex |
Yes |
| Link aggregation |
Yes |
| Ethernet LAN data rates |
10,1000,100 Mbit/s |
| VLAN support |
Yes |
| Number of VLANs |
256 |
| Power |
| Power source |
AC |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50/60 Hz |
| Input current |
7 A |
| Power consumption (typical) |
22.6 W |
| Power consumption (max) |
434.3 W |
| Power plug type |
Type F |
| Operational conditions |
| Operating temperature (T-T) |
-5 - 50 °C |
| Storage temperature (T-T) |
-25 - 70 °C |
| Operating relative humidity (H-H) |
5 - 90% |
| Storage relative humidity (H-H) |
5 - 95% |
| Operating altitude |
0 - 3000 m |
| Heat dissipation |
1482 BTU/h |
| Weight & dimensions |
| Width |
440 mm |
| Depth |
250 mm |
| Height |
44 mm |
| Weight |
3.89 kg |
| Security |
| DHCP features |
DHCP client |
| Access Control List (ACL) |
Yes |
| Access Control List (ACL) IPv4 entries |
256 |
| IGMP snooping |
Yes |
| SSH/SSL support |
Yes |
| Packaging data |
| Mounting brackets included |
Yes |
| Rubber feet |
Yes |
| Screws included |
Yes |
| Data transmission |
| MAC address table |
8000 entries |
| Switching capacity |
40 Gbit/s |
| Forwarding rate |
29.8 Mpps |
| Jumbo frames support |
Yes |
| Jumbo frames |
10000 |
| Packet buffer memory |
0.512 MB |
| Management features |
| Switch type |
Managed |
| Switch layer |
L2 |
| Quality of Service (QoS) support |
Yes |
| Web-based management |
Yes |
| Configuring Location Settings (CLI) |
Yes |
| MIB support |
RFC 1213 MIB-II RFC 1643 Ethernet MIB RFC 1493 Bridge MIB RFC 2131 DHCPv4 server and client Private Enterprise MIB (Allied Telesis provides the spec) |
| Optical fiber |
| Fiber ethernet cabling technology |
100BASE-FX, 1000BASE-SX, 1000BASE-LX |
| Other features |
| Size (imperial) |
48.3 cm (19") |
| Power over Ethernet (PoE) |
| Power over Ethernet (PoE) |
Yes |
| Power over Ethernet (PoE) type supported |
PoE+ |
| Power over Ethernet (PoE) ports quantity |
16 |
| Power over Ethernet plus (PoE+) ports quantity |
12 |
| Power over Ethernet (PoE) power per port |
30 W |
| Total Power over Ethernet (PoE) budget |
370 W |
| Design |
| Rack mounting |
Yes |
| Form factor |
Desktop/Wall-Mounting |
| Product colour |
Silver |
| Reset button |
Yes |
| LED indicators |
Yes |
| Wall mountable |
Yes |
| Performance |
| Memory type |
DRAM |
| Internal memory |
256 MB |
| Flash memory |
32 MB |
| Noise level |
51.7 dB |
| Telnet |
Yes |
| Fanless |
No |
| Multicast features |
| Multicast support |
Yes |
| Certification |
| Compliance certificates |
Trade Agreements Act (TAA), CE, UKCA, Federal Communications Commission (FCC), UL, TÜV mark, RoHS |
| Packaging content |
| Cables included |
Power |
| Rack mount kit |
Yes |
| Sustainability |
| Doesn't contain |
Lead, Mercury, Cadmium |
