Stock Status: 1x unit in stock
This desktop media converter features 1000T to 1000SX conversion with ST multi-mode fiber connector supporting a distances from 220m to 550m. At just 1.25 inches wide × 3.6 inches deep × 0.85 inches high, this media converter can easily fit into the palm of a hand.
Specs
| Networking |
| Maximum data transfer rate |
1000 Mbit/s |
| Converter input interface |
1000Base-T |
| Converter output interface |
1000Base-SX |
| Networking standards |
IEEE 802.1Q |
| Ethernet interface type |
Gigabit Ethernet |
| Data transfer rate |
1000 Mbit/s |
| Packet forwarding rate (10 Mbps) |
14880 pps |
| Packet forwarding rate (100 Mbps) |
148800 pps |
| Packet forwarding rate (1 Gbps) |
1488000 pps |
| VLAN support |
Yes |
| Auto MDI/MDI-X |
Yes |
| Duplex system |
Full, Half |
| Weight & dimensions |
| Width |
31.8 mm |
| Depth |
91.4 mm |
| Height |
21.6 mm |
| Weight |
113 g |
| Ports & interfaces |
| Fiber optic connector |
ST |
| Connectivity technology |
Wired |
| Power |
| Power consumption (typical) |
1.5 W |
| Operational conditions |
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-15 - 65 °C |
| Operating relative humidity (H-H) |
5 - 95% |
| Storage relative humidity (H-H) |
5 - 95% |
| Operating altitude |
0 - 3048 m |
| Design |
| Internal |
No |
| LED indicators |
Yes |
| Product colour |
Grey |
| Performance |
| Maximum transfer distance |
550 m |
| Wavelength |
850 nm |
| Fiber mode structure |
Multi-mode |
| Fiber cable diameters supported (core/cladding) |
50/125,62.5/125 µm |
| Tx power (min) |
-9.5 dBmW |
| Tx power (max) |
-4 dBmW |
| Rx power (min) |
-17 dBmW |
Features
Allied Telesis AT-DMC1000/ST-30. Maximum data transfer rate: 1000 Mbit/s, Converter input interface: 1000Base-T, Converter output interface: 1000Base-SX. Fiber optic connector: ST, Connectivity technology: Wired. Maximum transfer distance: 550 m, Wavelength: 850 nm, Fiber mode structure: Multi-mode. Product colour: Grey. Power consumption (typical): 1.5 W
Product Description
This desktop media converter features 1000T to 1000SX conversion with ST multi-mode fiber connector supporting a distances from 220m to 550m. At just 1.25 inches wide × 3.6 inches deep × 0.85 inches high, this media converter can easily fit into the palm of a hand.
