Stock Status: 1x unit in stock
HP Care Pack Support Plus Service provides comprehensive hardware & software services that increases the availability of your IT infrastructure.
• Provides 4-hour response for HP hardware.
Specs
| Ports & interfaces |
| Basic switching RJ-45 Ethernet ports quantity |
5 |
| Basic switching RJ-45 Ethernet ports type |
Gigabit Ethernet (10/100/1000) |
| Installed SFP modules quantity |
0 |
| Installed SFP+ modules quantity |
0 |
| 2.5G Ethernet (copper) ports quantity |
5 |
| Networking |
| Networking standards |
IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x |
| 10G support |
No |
| Copper ethernet cabling technology |
10BASE-T, 100BASE-TX, 1000BASE-T |
| Cable types supported |
Cat3, Cat4, Cat5, Cat5e |
| Flow control support |
Yes |
| Auto MDI/MDI-X |
Yes |
| Auto-negotiation |
Yes |
| MAC address auto-learning supported |
Yes |
| MAC address auto-aging supported |
Yes |
| Power |
| Power source |
DC/PoE |
| Power supply included |
Yes |
| Number of power supply units |
1 |
| AC input voltage |
220 V |
| AC input frequency |
50 Hz |
| Input current |
2.43 A |
| Input voltage |
53.5 V |
| Power consumption (max) |
143.37 W |
| Operational conditions |
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-40 - 70 °C |
| Operating relative humidity (H-H) |
10 - 90% |
| Storage relative humidity (H-H) |
5 - 90% |
| Heat dissipation |
488.89 BTU/h |
| Weight & dimensions |
| Width |
209 mm |
| Depth |
126 mm |
| Height |
26 mm |
| Security |
| IGMP snooping |
Yes |
| Packaging data |
| Package type |
Box |
| Data transmission |
| MAC address table |
4000 entries |
| Switching capacity |
25 Gbit/s |
| Forwarding rate |
18.6 Mpps |
| Store-and-forward |
Yes |
| Management features |
| Switch type |
Unmanaged |
| Quality of Service (QoS) support |
Yes |
| Power over Ethernet (PoE) |
| Power over Ethernet (PoE) |
Yes |
| Power over Ethernet 4PPoE (PoE++) ports quantity |
4 |
| Power over Ethernet (PoE) power per port |
60 W |
| Total Power over Ethernet (PoE) budget |
123 W |
| Design |
| Rack mounting |
No |
| Product colour |
Black |
| Housing material |
Steel |
| LED indicators |
Yes |
| Performance |
| Fanless |
Yes |
| Certification |
| Certification |
CE, FCC, RoHS |
| Packaging content |
| Cables included |
AC |
| User guide |
Yes |
Features
TP-Link 5-Port 2.5G Desktop Switch with 4-Port PoE++. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 5. MAC address table: 4000 entries, Switching capacity: 25 Gbit/s. Networking standards: IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x. Power over Ethernet (PoE)
Product Description
HP Care Pack Support Plus Service provides comprehensive hardware & software services that increases the availability of your IT infrastructure.
• Provides 4-hour response for HP hardware.
