Ports & interfaces |
Basic switching RJ-45 Ethernet ports quantity |
24 |
Basic switching RJ-45 Ethernet ports type |
Gigabit Ethernet (10/100/1000) |
Combo SFP ports quantity |
2 |
Networking |
Networking standards |
IEEE 802.11ad, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
Broadcast storm control |
Y |
Virtual LAN features |
Private VLAN, Port-based VLAN |
Operational conditions |
Operating temperature (T-T) |
0 - 40 °C |
Operating relative humidity (H-H) |
10 - 90% |
Weight & dimensions |
Width |
442 mm |
Depth |
212 mm |
Height |
44 mm |
Weight |
3.1 kg |
Security |
SSH/SSL support |
Y |
Data transmission |
MAC address table |
8000 entries |
Throughput |
52000 Mpps |
Store-and-forward |
Y |
Management features |
Switch type |
Managed |
Power over Ethernet (PoE) |
Power over Ethernet (PoE) |
Y |
Design |
Rack mounting |
Y |
Stackable |
Y |
Form factor |
1U |
Product colour |
Black |
Certification |
CE EN 60950-1, EN 55022, EN 55024
FCC FCC Part 15 (CFR47) Class A |
Logistics data |
Harmonized System (HS) code |
85176990 |
