| Ports & interfaces |
| Basic switching RJ-45 Ethernet ports quantity |
20 |
| Basic switching RJ-45 Ethernet ports type |
Gigabit Ethernet (10/100/1000) |
| Installed SFP+ modules quantity |
4 |
| Gigabit Ethernet (copper) ports quantity |
20 |
| Combo SFP ports quantity |
4 |
| Console port |
RJ-45/Mini-USB |
| USB 2.0 ports quantity |
1 |
| Networking |
| Networking standards |
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1Qbb, IEEE 802.1ag, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ah, IEEE 802.3x, IEEE 802.3z |
| 10G support |
Yes |
| Copper ethernet cabling technology |
10BASE-T, 100BASE-TX, 1000BASE-T |
| Port mirroring |
Yes |
| Full duplex |
Yes |
| Routing entries |
16000 |
| Flow control support |
Yes |
| Link aggregation |
Yes |
| Broadcast storm control |
Yes |
| Spanning tree protocol |
Yes |
| VLAN support |
Yes |
| Virtual LAN features |
Stacked VLAN, Private VLAN, Tagged VLAN, Port-based VLAN |
| Number of VLANs |
4094 |
| Power |
| Power supply included |
Yes |
| Redundant power supply (RPS) support |
Yes |
| Number of power supply units |
1 |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50 - 60 Hz |
| Power consumption (max) |
42.4 W |
| Operational conditions |
| Operating temperature (T-T) |
-5 - 50 °C |
| Storage temperature (T-T) |
-40 - 70 °C |
| Operating relative humidity (H-H) |
10 - 95% |
| Storage relative humidity (H-H) |
5 - 95% |
| Heat dissipation |
145 BTU/h |
| Weight & dimensions |
| Width |
441 mm |
| Depth |
260 mm |
| Height |
44 mm |
| Weight |
3.74 kg |
| Security |
| DHCP features |
DHCP server, DHCP client |
| Access Control List (ACL) |
Yes |
| IGMP snooping |
Yes |
| Security algorithms |
802.1x RADIUS, SSH, SSH-2, SSL/TLS |
| MAC address filtering |
Yes |
| SSH/SSL support |
Yes |
| Loop protection |
Yes |
| BPDU filtering/protection |
Yes |
| Authentication |
Guest VLAN, Port-based authentication |
| Data transmission |
| MAC address table |
68000 entries |
| Switching capacity |
128 Gbit/s |
| Throughput |
95.24 Mpps |
| Number of queues |
8 |
| Number of IP interfaces |
256 |
| Jumbo frames support |
Yes |
| Jumbo frames |
12000 |
| Packet buffer memory |
4 MB |
| Management features |
| Switch type |
Managed |
| Switch layer |
L3 |
| Quality of Service (QoS) support |
Yes |
| Web-based management |
Yes |
| Traffic classification |
Yes |
| ARP inspection |
Yes |
| System event log |
Yes |
| Protocols |
| Management protocols |
SNMP, NTPv3/v4, Telnet |
| Supported network protocols |
IPv4/v6 |
| Power over Ethernet (PoE) |
| Power over Ethernet (PoE) |
No |
| Design |
| Rack mounting |
Yes |
| Stackable |
Yes |
| Form factor |
1U |
| Product colour |
Black |
| LED indicators |
Yes |
| Number of fans |
2 fan(s) |
| Safety |
cUL, CB, CE, CCC, BSM |
| Electromagnetic compatibility |
CE, FCC Class A, C-Tick, VCCI, BSMI, CCC |
| Performance |
| Virtual stacking (units) |
32 |
| Noise level |
52.7 dB |
| Mean time between failures (MTBF) |
300190 h |
| Multicast features |
| Multicast support |
Yes |
