| Audio |
| Built-in speaker(s) |
Yes |
| Number of speakers |
1 |
| Operational conditions |
| Operating temperature (T-T) |
0 - 40 °C |
| Operating relative humidity (H-H) |
10 - 95% |
| Storage temperature (T-T) |
-40 - 70 °C |
| Weight & dimensions |
| Interface module dimensions (W x D x H) |
246.2 x 171.3 x 56.1 mm |
| Interface module weight |
1 kg |
| Width |
161 mm |
| Depth |
211 mm |
| Height |
34.5 mm |
| Package width |
252 mm |
| Package depth |
373 mm |
| Package height |
189 mm |
| Package weight |
5 kg |
| Ports & interfaces |
| HDMI ports quantity |
3 |
| HDMI output ports quantity |
2 |
| HDMI input ports quantity |
1 |
| USB connector type |
USB Type-A |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
3 |
| Ethernet LAN (RJ-45) ports |
1 |
| Networking |
| Ethernet LAN |
Yes |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Wi-Fi |
Yes |
| Wi-Fi standards |
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Security algorithms |
128-bit AES |
| Power |
| Power source type |
AC |
| AC input voltage |
100 - 240 V |
| Current |
4.74 A |
| DC input voltage |
19 V |
| Battery technology |
Lithium |
| Battery capacity |
220 mAh |
| Number of batteries supported |
2 |
| Power plug type |
Type G |
| Display |
| Display |
IPS |
| Display diagonal |
25.6 cm (10.1") |
| Display resolution |
1280 x 800 pixels |
| Contrast ratio (typical) |
1000:1 |
| Touchscreen |
Yes |
| Touchscreen type |
Capacitive |
| Viewing angle, horizontal |
85° |
| Viewing angle, vertical |
85° |
| Display brightness |
400 cd/m² |
| Oleophobic coating |
Yes |
| Packaging content |
| Cables included |
AC, DC |
| Power cable length |
2.5 m |
| AC adapter included |
Yes |
| Mounting kit |
Yes |
| Quick start guide |
Yes |
| Interface module |
| Interface module RJ-45 ports quantity |
1 |
| Features |
| Telepresence |
No |
| Motion sensor |
Yes |
| Cable lock slot |
Yes |
| Cable lock slot type |
Kensington |
| Logistics data |
| Master (outer) case gross weight |
5 kg |
| Master (outer) case length |
380 mm |
| Master (outer) case width |
259 mm |
| Master (outer) case height |
203 mm |
| Harmonized System (HS) code |
85176990 |
| Battery |
| Battery capacity |
0.675 Wh |
| Computer system |
| VESA mounting |
Yes |
| Operating system installed |
CollabOS |
| Performance |
| Product colour |
Graphite, White |
| Bluetooth |
Yes |
| Bluetooth version |
5.0 |
