| Ports & interfaces |
| Basic switching RJ-45 Ethernet ports quantity |
48 |
| Basic switching RJ-45 Ethernet ports type |
Gigabit Ethernet (10/100/1000) |
| Combo SFP ports quantity |
2 |
| SFP module slots quantity |
2 |
| Networking |
| Networking standards |
IEEE 802.1D, IEEE 802.1as, IEEE 802.1s, IEEE 802.1v, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| Copper ethernet cabling technology |
10BASE-T, 100BASE-TX, 100BASE-T, 1000BASE-T |
| Port mirroring |
Yes |
| Full duplex |
Yes |
| IP routing |
Yes |
| Flow control support |
Yes |
| Broadcast storm control |
Yes |
| Spanning tree protocol |
Yes |
| VLAN support |
Yes |
| Number of VLANs |
256 |
| Power |
| AC input voltage |
100 - 240 V |
| Power consumption (typical) |
41.1 W |
| Operational conditions |
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-20 - 70 °C |
| Operating relative humidity (H-H) |
0 - 90% |
| Storage relative humidity (H-H) |
0 - 95% |
| Operating altitude |
0 - 3000 m |
| Non-operating altitude |
0 - 3000 m |
| Weight & dimensions |
| Width |
440 mm |
| Depth |
257 mm |
| Height |
43 mm |
| Weight |
3.46 kg |
| Security |
| DHCP features |
DHCP client |
| Access Control List (ACL) |
Yes |
| IGMP snooping |
Yes |
| Security algorithms |
802.1x RADIUS, HTTPS, SSL/TLS |
| MAC address filtering |
Yes |
| SSH/SSL support |
Yes |
| Data transmission |
| MAC address table |
16000 entries |
| Switching capacity |
100 Gbit/s |
| Store-and-forward |
Yes |
| Number of queues |
8 |
| Number of static routes |
32 |
| Jumbo frames support |
Yes |
| Management features |
| Switch type |
Managed |
| Switch layer |
L2/L3/L4 |
| Quality of Service (QoS) support |
Yes |
| Web-based management |
Yes |
| System event log |
Yes |
| Protocols |
| Management protocols |
SNMP v1/v2 |
| Supported network protocols |
IP |
| Power over Ethernet (PoE) |
| Power over Ethernet (PoE) |
No |
| Design |
| Rack mounting |
Yes |
| Product colour |
Black, Grey |
| LED indicators |
Activity, Link, Power |
| Performance |
| Noise level |
37.2 dB |
| Firmware upgradeable |
Yes |
| Mean time between failures (MTBF) |
390728 h |
| Multicast features |
| Multicast support |
Yes |
| Number of multicast groups filtered |
512 |
| Certification |
| Certification |
CE, FCC, VCCI, EN, C-Tick, CCC, CSA, UL/cUL, IEC |
| Packaging content |
| Cables included |
AC |
| Manual |
Yes |
