| Ports & interfaces |
| Basic switching RJ-45 Ethernet ports quantity |
4 |
| Basic switching RJ-45 Ethernet ports type |
Gigabit Ethernet (10/100/1000) |
| Installed SFP modules quantity |
0 |
| Installed SFP+ modules quantity |
0 |
| Gigabit Ethernet (copper) ports quantity |
5 |
| Power connector |
DC-in jack |
| Networking |
| Networking standards |
IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x |
| 10G support |
No |
| Copper ethernet cabling technology |
10BASE-T, 100BASE-TX, 1000BASE-T |
| Full duplex |
Yes |
| Auto MDI/MDI-X |
Yes |
| Auto-sensing |
Yes |
| Auto-negotiation |
Yes |
| Cable length detection |
Yes |
| Power |
| Power source |
DC |
| DC input voltage |
54 V |
| Input current |
1.66 A |
| Power consumption (typical) |
2.89 W |
| Power consumption (max) |
88.89 W |
| Operational conditions |
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-20 - 70 °C |
| Operating relative humidity (H-H) |
10 - 90% |
| Storage relative humidity (H-H) |
5 - 95% |
| Heat dissipation |
304 BTU/h |
| Weight & dimensions |
| Width |
158 mm |
| Depth |
101 mm |
| Height |
29 mm |
| Weight |
410 g |
| Packaging data |
| Package width |
269 mm |
| Package depth |
73 mm |
| Package height |
215 mm |
| Package weight |
1.3 kg |
| Data transmission |
| MAC address table |
2000 entries |
| Switching capacity |
10 Gbit/s |
| Forwarding rate |
1.448 Mpps |
| Latency (1 Gbps) |
2.4 µs |
| Jumbo frames support |
Yes |
| Jumbo frames |
9216 |
| Packet buffer memory |
128 MB |
| Management features |
| Switch type |
Unmanaged |
| Quality of Service (QoS) support |
Yes |
| Power over Ethernet (PoE) |
| Power over Ethernet (PoE) |
Yes |
| Power over Ethernet plus (PoE+) ports quantity |
4 |
| Power over Ethernet (PoE) power per port |
30 W |
| Total Power over Ethernet (PoE) budget |
83 W |
| Design |
| Rack mounting |
No |
| Product colour |
Black |
| Housing material |
Metal |
| Reset button |
Yes |
| LED indicators |
Activity, Link, PoE, Power |
| Wall mountable |
Yes |
| Performance |
| Mean time between failures (MTBF) |
6710127 h |
| Logistics data |
| Master (outer) case width |
237 mm |
| Master (outer) case length |
469 mm |
| Master (outer) case height |
306 mm |
| Master (outer) case gross weight |
8.52 kg |
| Products per master (outer) case |
6 pc(s) |
| Certification |
| Certification |
CE Mark, FCC Part 15 Class B, IC Class B, RCM, CCC, VCCI, CB, CE
VD, CCC |
| Packaging content |
| Manual |
Yes |
