| Ports & interfaces |
| Basic switching RJ-45 Ethernet ports quantity |
7 |
| Basic switching RJ-45 Ethernet ports type |
10G Ethernet (100/1000/10000) |
| Installed SFP+ modules quantity |
1 |
| Console port |
RJ-45 |
| Power connector |
DC-in jack |
| Networking |
| Networking standards |
IEEE 802.1p,IEEE 802.3,IEEE 802.3ab,IEEE 802.3ae,IEEE 802.3an,IEEE 802.3aq,IEEE 802.3az,IEEE 802.3bz,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z |
| 10G support |
Y |
| Power |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50 - 60 Hz |
| Input current |
1.5 A |
| Power consumption (typical) |
21.31 W |
| Power consumption (max) |
39 W |
| Operational conditions |
| Operating temperature (T-T) |
0 - 50 °C |
| Storage temperature (T-T) |
-20 - 70 °C |
| Operating relative humidity (H-H) |
0 - 95% |
| Storage relative humidity (H-H) |
0 - 95% |
| Operating altitude |
0 - 3000 m |
| Heat dissipation |
147.86 BTU/h |
| Weight & dimensions |
| Width |
328 mm |
| Depth |
169 mm |
| Height |
43.2 mm |
| Weight |
1.49 kg |
| Data transmission |
| MAC address table |
2000 entries |
| Switching capacity |
160 Gbit/s |
| Jumbo frames support |
Y |
| Jumbo frames |
9000 |
| Management features |
| Switch type |
Unmanaged |
| Quality of Service (QoS) support |
Y |
| Design |
| Rack mounting |
Y |
| Product colour |
Grey, Silver |
| LED indicators |
Y |
| Safety |
CE: CB 60950-1, LVD 60950-1, AUS/NZ: AS/NZS 60950-1, USA: UL 60950-1, SNE VA, BSMI |
| Certification |
47 CFR FCC, ICES-003:2016 Issue 6, ANSI C63.4:2014, EN 55032:2012+AC2013, EN 55024:2010, EN 61000-3-2:2014, EN 6100-3-3:2013, AS/NZS CISPR 32:2015, VCCI V-3/2015.04, V-4/2012.4, CNS 13438 |
| Performance |
| Mean time between failures (MTBF) |
1145157 h |
