Stock Status: 1x unit in stock
LGS3 Range
Managed PoE+ Max Power Gigabit Switches
Managed PoE+ Gigabit Switch
Managed Gigabit Switches
Designed for security and speed, Linksys Managed Gigabit Switches
provide a business-class network you can grow on
Network Expansion
Our managed switches include features for quickly expanding and growing your network. Multiple high-bandwidth trunks between switches enhance availability and redundancy. Spanning Tree Protocol (STP) and Storm Control features help control planned or inadvertent cable loops, so you can confidently build a mesh of switches and quickly expand your network to support your growing workforce.
Network Security
Unauthorised access to the network and mission-critical data is a constant concern. Our managed switches help secure networks through port authentication, requiring clients to authenticate themselves before any data is passed. Advanced DHCP snooping and IP-MAC binding functions ensure network integrity and help prevent network attacks.
Quality of Service (QoS)
Numerous QoS features ensure that traffic is prioritized properly to deliver the best possible user experience for real-time applications like voice and video along with bandwidth-intensive graphic/video file uploads and downloads. IGMP snooping limits IP multicast traffic to the ports that requested it, enabling the rest of the network to operate at peak efficiency.
Power over Ethernet Plus (PoE+)
Linksys managed switches support the latest 802.3at (PoE+) standards and provide up to double the power budget per Gigabit Ethernet port while offering 802.3af (PoE) backward- compatibility. Power over Ethernet reduces electrical wiring costs, simplifies installation, and supports network devices such as IP cameras and wireless access points in optimal indoor and outdoor locations.
Specs
| Ports & interfaces |
| Basic switching RJ-45 Ethernet ports quantity |
8 |
| Basic switching RJ-45 Ethernet ports type |
Gigabit Ethernet (10/100/1000) |
| Gigabit Ethernet (copper) ports quantity |
8 |
| SFP+ module slots quantity |
2 |
| Networking |
| Networking standards |
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| 10G support |
No |
| Port mirroring |
Yes |
| Link aggregation |
Yes |
| Broadcast storm control |
Yes |
| Rate limiting |
Yes |
| Spanning tree protocol |
Yes |
| Head-of-line (HOL) blocking |
Yes |
| VLAN support |
Yes |
| Virtual LAN features |
Port-based VLAN |
| Number of VLANs |
256 |
| Power |
| Power source |
AC |
| Power supply included |
Yes |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50 - 60 Hz |
| Input current |
2.2 A |
| Power consumption (max) |
133.77 W |
| Operational conditions |
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-20 - 70 °C |
| Operating relative humidity (H-H) |
10 - 90% |
| Storage relative humidity (H-H) |
5 - 95% |
| Weight & dimensions |
| Width |
104.9 mm |
| Depth |
240 mm |
| Height |
26.9 mm |
| Weight |
288.5 g |
| Security |
| DHCP features |
DHCP client, DHCP relay, DHCP snooping |
| Access Control List (ACL) |
Yes |
| IGMP snooping |
Yes |
| Security algorithms |
HTTPS, SNMP |
| Static port security |
Yes |
| SSH/SSL support |
Yes |
| Loop protection |
Yes |
| IP-MAC-Port binding |
Yes |
| Authentication |
Guest VLAN |
| Authentication type |
RADIUS |
| Packaging data |
| Package type |
Box |
| Package width |
156.6 mm |
| Package depth |
281.4 mm |
| Package height |
101.1 mm |
| Package weight |
1.92 kg |
| Data transmission |
| MAC address table |
8000 entries |
| Switching capacity |
20 Gbit/s |
| Forwarding rate |
14.88 Mpps |
| Jumbo frames support |
Yes |
| Jumbo frames |
10000 |
| Management features |
| Switch type |
Managed |
| Switch layer |
L3 |
| Quality of Service (QoS) support |
Yes |
| Protocols |
| Management protocols |
HTTP, HTTPS |
| IPv4 FIB entries |
63 |
| IPv6 FIB entries |
21 |
| Power over Ethernet (PoE) |
| Power over Ethernet (PoE) |
Yes |
| Power over Ethernet plus (PoE+) ports quantity |
8 |
| Design |
| Stackable |
Yes |
| Product colour |
Black, Blue |
| Housing material |
Metal |
| LED indicators |
Fault, Power |
| Performance |
| Memory type |
DRAM |
| Internal memory |
256 MB |
| Firmware upgradeable |
Yes |
| Logistics data |
| Country of origin |
Taiwan |
| Master (outer) case width |
178.3 mm |
| Master (outer) case length |
540 mm |
| Master (outer) case height |
302.3 mm |
| Harmonized System (HS) code |
85176990 |
| Master (outer) case gross weight |
10.3 kg |
| Products per master (outer) case |
5 pc(s) |
| Multicast features |
| Multicast support |
Yes |
Features
Linksys 8 Port Gigabit Network PoE+ Switch. Switch type: Managed, Switch layer: L3. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 8. MAC address table: 8000 entries, Switching capacity: 20 Gbit/s. Networking standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE.... Power over Ethernet (PoE)
Product Description
LGS3 Range
Managed PoE+ Max Power Gigabit Switches
Managed PoE+ Gigabit Switch
Managed Gigabit Switches
Designed for security and speed, Linksys Managed Gigabit Switches
provide a business-class network you can grow on
Network Expansion
Our managed switches include features for quickly expanding and growing your network. Multiple high-bandwidth trunks between switches enhance availability and redundancy. Spanning Tree Protocol (STP) and Storm Control features help control planned or inadvertent cable loops, so you can confidently build a mesh of switches and quickly expand your network to support your growing workforce.
Network Security
Unauthorised access to the network and mission-critical data is a constant concern. Our managed switches help secure networks through port authentication, requiring clients to authenticate themselves before any data is passed. Advanced DHCP snooping and IP-MAC binding functions ensure network integrity and help prevent network attacks.
Quality of Service (QoS)
Numerous QoS features ensure that traffic is prioritized properly to deliver the best possible user experience for real-time applications like voice and video along with bandwidth-intensive graphic/video file uploads and downloads. IGMP snooping limits IP multicast traffic to the ports that requested it, enabling the rest of the network to operate at peak efficiency.
Power over Ethernet Plus (PoE+)
Linksys managed switches support the latest 802.3at (PoE+) standards and provide up to double the power budget per Gigabit Ethernet port while offering 802.3af (PoE) backward- compatibility. Power over Ethernet reduces electrical wiring costs, simplifies installation, and supports network devices such as IP cameras and wireless access points in optimal indoor and outdoor locations.
