| Ports & interfaces |
| Basic switching RJ-45 Ethernet ports quantity |
8 |
| Basic switching RJ-45 Ethernet ports type |
Gigabit Ethernet (10/100/1000) |
| Installed SFP modules quantity |
0 |
| Installed SFP+ modules quantity |
0 |
| Networking |
| Networking standards |
IEEE 802.3az, IEEE 802.1p, IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3af, IEEE 802.3at |
| 10G support |
No |
| Copper ethernet cabling technology |
10BASE-T, 100BASE-TX, 1000BASE-T |
| Cable types supported |
Cat5e |
| Full duplex |
Yes |
| Half duplex |
Yes |
| Flow control support |
Yes |
| Auto MDI/MDI-X |
Yes |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Auto-sensing |
Yes |
| Auto-negotiation |
Yes |
| MAC address auto-learning supported |
Yes |
| MAC address auto-aging supported |
Yes |
| Power |
| Power source |
DC |
| Power supply included |
Yes |
| Number of power supply units |
1 |
| DC input voltage |
54 V |
| Input current |
1.25 A |
| Input voltage |
54 V |
| Power consumption (max) |
67.5 W |
| Operational conditions |
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-20 - 70 °C |
| Operating relative humidity (H-H) |
0 - 90% |
| Storage relative humidity (H-H) |
0 - 95% |
| Operating altitude |
0 - 3000 m |
| Heat dissipation |
230.85 BTU/h |
| Weight & dimensions |
| Width |
236 mm |
| Depth |
102 mm |
| Height |
27 mm |
| Weight |
600 g |
| Security |
| Queue scheduling algorithms |
Weighted Round Robin (WRR) |
| MAC address entries |
Dynamic MAC address entries |
| Data transmission |
| MAC address table |
4000 entries |
| Switching capacity |
16 Gbit/s |
| Throughput |
16 Gbit/s |
| Forwarding rate |
1.488 Mpps |
| Latency (1 Gbps) |
2.6 µs |
| Number of queues |
8 |
| Jumbo frames support |
Yes |
| Jumbo frames |
9216 |
| Packet forwarding rate (1 Gbps) |
1488000 pps |
| Packet buffer memory |
0.192 MB |
| Management features |
| Switch type |
Unmanaged |
| Quality of Service (QoS) support |
Yes |
| Traffic classification |
Yes |
| Power over Ethernet (PoE) |
| Power over Ethernet (PoE) |
Yes |
| Power over Ethernet (PoE) type supported |
PoE+ |
| Power over Ethernet (PoE) ports quantity |
8 |
| Power over Ethernet plus (PoE+) ports quantity |
8 |
| Power over Ethernet (PoE) power per port |
30 W |
| Total Power over Ethernet (PoE) budget |
60 W |
| Design |
| Rack mounting |
Yes |
| Stackable |
No |
| Form factor |
Desktop |
| Product colour |
Black |
| Housing material |
Metal |
| LED indicators |
Yes |
| Wall mountable |
Yes |
| Performance |
| Fanless |
Yes |
| Mean time between failures (MTBF) |
2752476 h |
| Certification |
| Compliance certificates |
CE, Federal Communications Commission (FCC), Industry Canada (IC), RCM, VCCI, KC, CB, Low Voltage Directive (LVD) |
