Stock Status: 1x unit in stock
1000 Mbps (1 Gbps) | Multi Mode Fiber | LC | 550 m (1804 ft) | TAA | Lifetime Warranty
The SFPSXMM is a TAA compliant MSA compliant fiber SFP transceiver that’s designed, programmed and tested to work with 1000BASE-SX compatible MSA switches and routers. The SFP transceiver module supports a maximum distance of up to 550 m (1804 ft) and delivers dependable 10 GbE connectivity over fiber cabling.
Technical Specifications:
Wavelength: 850 nm
Maximum Data Transfer Rate: 1.25 Gbps
Type: Multi Mode Fiber
Connection Type: LC Connector
Maximum Transfer Distance: 550 m (1804 ft)
MTBF: 78,286 hours
Power Consumption: Less than 1 Watt
DDM: No
This SFP+ fiber module is hot-swappable, making upgrades and replacements seamless by minimizing network disruptions.
StarTech.com SFPs
All StarTech.com SFP & SFP+ transceiver modules are backed by a lifetime warranty and free lifetime multilingual technical support. StarTech.com offers a wide variety of SFP modules and direct-attach SFP Cables, providing the convenience and reliability you need to ensure dependable network performance.
The StarTech.com Advantage
- StarTech.com SFP modules are backed by a lifetime warranty
- Delivers reliable 1 GbE connections for 1000BASE-SX compliant networks
- Hot-swappable with fiber-optic modules
Specs
| Operational conditions |
| Operating temperature (T-T) |
0 - 70 °C |
| Storage temperature (T-T) |
-40 - 85 °C |
| Operating relative humidity (H-H) |
5 - 95% |
| Weight & dimensions |
| Width |
13 mm |
| Depth |
55 mm |
| Height |
9 mm |
| Weight |
18 g |
| Power |
| Power consumption (typical) |
1 W |
| Other features |
| Dimensions (WxDxH) |
13 x 55 x 9 mm |
| Performance |
| SFP transceiver type |
Fiber optic |
| Maximum data transfer rate |
1250 Mbit/s |
| Interface type |
SFP |
| Multi-mode fiber (MMF) supported |
Y |
| Fiber optic connector |
LC |
| SFP transceiver standard |
SX |
| Maximum transfer distance |
550 m |
| Wavelength |
850 nm |
| Networking standards |
IEEE 802.3z |
| Duplex system |
Full |
| Digital Diagnostics Monitoring (DDM) |
N |
| Fiber ethernet cabling technology |
1000BASE‑SX |
| Features |
| Product colour |
Silver |
| Mean time between failures (MTBF) |
78286 h |
| RoHS compliance |
Y |
| Certification |
CE, FCC, UL, TAA, REACH |
| Hot-swap |
Y |
| Brand compatibility |
MSA Compliant |
| Logistics data |
| Master (outer) case width |
22 cm |
| Master (outer) case length |
56 cm |
| Master (outer) case height |
21 cm |
| Quantity per master (outer) case |
100 pc(s) |
| Products per master (outer) case |
100 pc(s) |
| Packaging data |
| Number of products included |
1 pc(s) |
| Package width |
25 mm |
| Package depth |
115 mm |
| Package height |
65 mm |
| Package weight |
40 g |
| Technical details |
| Sustainability certificates |
RoHS |
Features
StarTech.com MSA Uncoded SFP Module - 1000BASE-SX - 1GbE Multi Mode Fiber (MMF) Optic Transceiver - 1GE Gigabit Ethernet SFP - LC 550m - 850nm - DDM. SFP transceiver type: Fiber optic, Maximum data transfer rate: 1250 Mbit/s, Interface type: SFP. Product colour: Silver, Mean time between failures (MTBF): 78286 h, Brand compatibility: MSA Compliant. Power consumption (typical): 1 W. Width: 13 mm, Depth: 55 mm, Height: 9 mm. Number of products included: 1 pc(s), Package width: 25 mm, Package depth: 115 mm
Product Description
1000 Mbps (1 Gbps) | Multi Mode Fiber | LC | 550 m (1804 ft) | TAA | Lifetime Warranty
The SFPSXMM is a TAA compliant MSA compliant fiber SFP transceiver that’s designed, programmed and tested to work with 1000BASE-SX compatible MSA switches and routers. The SFP transceiver module supports a maximum distance of up to 550 m (1804 ft) and delivers dependable 10 GbE connectivity over fiber cabling.
Technical Specifications:
Wavelength: 850 nm
Maximum Data Transfer Rate: 1.25 Gbps
Type: Multi Mode Fiber
Connection Type: LC Connector
Maximum Transfer Distance: 550 m (1804 ft)
MTBF: 78,286 hours
Power Consumption: Less than 1 Watt
DDM: No
This SFP+ fiber module is hot-swappable, making upgrades and replacements seamless by minimizing network disruptions.
StarTech.com SFPs
All StarTech.com SFP & SFP+ transceiver modules are backed by a lifetime warranty and free lifetime multilingual technical support. StarTech.com offers a wide variety of SFP modules and direct-attach SFP Cables, providing the convenience and reliability you need to ensure dependable network performance.
The StarTech.com Advantage
- StarTech.com SFP modules are backed by a lifetime warranty
- Delivers reliable 1 GbE connections for 1000BASE-SX compliant networks
- Hot-swappable with fiber-optic modules
