| Networking |
| Maximum data transfer rate |
5000 Mbit/s |
| Networking standards |
IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u |
| Ethernet LAN |
Y |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Cabling technology |
10/100/1000BaseT(X) |
| Wi-Fi |
N |
| Wake-on-LAN ready |
Y |
| Auto MDIX IEEE |
Y |
| Full duplex |
Y |
| Jumbo frames support |
Y |
| System requirements |
| Windows operating systems supported |
Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 x64, Windows 7, Windows |
| Mac operating systems supported |
Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur, Mac |
| Linux operating systems supported |
Y |
| Server operating systems supported |
Windows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019 |
| Weight & dimensions |
| Width |
65 mm |
| Depth |
92 mm |
| Height |
20 mm |
| Weight |
65 g |
| Ports & interfaces |
| Connectivity technology |
Wired |
| Host interface |
USB |
| Ethernet LAN (RJ-45) ports |
1 |
| USB version |
3.2 Gen 1 (3.1 Gen 1) |
| Operational conditions |
| Operating temperature (T-T) |
0 - 50 °C |
| Storage temperature (T-T) |
-20 - 60 °C |
| Operating relative humidity (H-H) |
5 - 85% |
| Other features |
| Connection to PC |
Y |
| AC input voltage |
115-230 V |
| Ports quantity |
3 |
| Data transfer rate |
5000 Mbit/s |
| Harmonized System (HS) code |
85176990 |
| Design |
| Internal |
N |
| Product colour |
Black, White |
| Chipset |
ASIX AX88179 + VIA VL811 |
| Hot-swap |
Y |
| Plug and Play |
Y |
| LED indicators |
Activity, Link, Power |
| Logistics data |
| Master (outer) case width |
332 mm |
| Master (outer) case length |
537 mm |
| Master (outer) case height |
329 mm |
| Products per master (outer) case |
40 pc(s) |
| Packaging data |
| Quantity |
1 |
| Drivers included |
Y |
| Package width |
162 mm |
| Package depth |
165 mm |
| Package height |
53 mm |
| Package weight |
344 g |
| Packaging content |
| Cables included |
USB |
| Manual |
Y |
| Sustainability |
| Sustainability compliance |
Y |
| Sustainability certificates |
CE, RoHS |
