| Ports & interfaces |
| Basic switching RJ-45 Ethernet ports quantity |
16 |
| Basic switching RJ-45 Ethernet ports type |
Gigabit Ethernet (10/100/1000) |
| Copper ethernet cabling technology |
10BASE-T,100BASE-TX,1000BASE-T |
| Gigabit Ethernet (copper) ports quantity |
16 |
| Installed SFP modules quantity |
0 |
| Installed SFP+ modules quantity |
0 |
| Networking |
| Networking standards |
IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x |
| 10G support |
No |
| Full duplex |
Yes |
| Cable types supported |
Cat3, Cat4, Cat5, Cat5e, Cat6 |
| Flow control support |
Yes |
| Port mirroring |
Yes |
| Link aggregation |
Yes |
| Broadcast storm control |
Yes |
| Rate limiting |
Yes |
| Auto MDI/MDI-X |
Yes |
| Copper ethernet cabling technology |
10BASE-T, 100BASE-TX, 1000BASE-T |
| Auto-negotiation |
Yes |
| VLAN support |
Yes |
| Virtual LAN features |
Port-based VLAN, Tagged VLAN |
| Number of VLANs |
4000 |
| Power |
| Power consumption (max) |
124.4 W |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50 - 60 Hz |
| Power supply included |
Yes |
| Operational conditions |
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-40 - 70 °C |
| Operating relative humidity (H-H) |
10 - 90% |
| Storage relative humidity (H-H) |
5 - 90% |
| Weight & dimensions |
| Width |
294 mm |
| Depth |
180 mm |
| Height |
44 mm |
| System requirements |
| Compatible operating systems |
Windows |
| Security |
| IGMP snooping |
Yes |
| Loop protection |
Yes |
| Static port security |
Yes |
| Packaging data |
| Cables included |
AC |
| Rack mount kit |
Yes |
| Resource CD |
Y |
| Data transmission |
| MAC address table |
8000 entries |
| Switching capacity |
32 Gbit/s |
| Throughput |
23.8 Mpps |
| Store-and-forward |
Yes |
| Number of queues |
4 |
| Jumbo frames support |
Yes |
| Jumbo frames |
10000 |
| Management features |
| Switch type |
Managed |
| Quality of Service (QoS) support |
Yes |
| Web-based management |
Yes |
| Switch layer |
L2 |
| Power over Ethernet (PoE) |
| Power over Ethernet (PoE) |
Yes |
| Power over Ethernet plus (PoE+) ports quantity |
8 |
| Power over Ethernet (PoE) power per port |
30 W |
| Total Power over Ethernet (PoE) budget |
110 W |
| Design |
| Stackable |
No |
| Product colour |
Black |
| LED indicators |
Yes |
| Certification |
FCC, CE, RoHS |
| Rack mounting |
Yes |
| Number of fans |
1 fan(s) |
| Performance |
| Auto-negotiation |
Y |
| Compatible operating systems |
Windows |
| Harmonized System (HS) code |
85176990 |
| Packaging content |
| Cables included |
AC |
| Rack mount kit |
Y |
| Resource CD |
Y |
| Logistics data |
| Harmonized System (HS) code |
85176990 |
| Virtual LAN features |
| VLAN support |
Y |
| Number of VLANs |
4000 |
| Tagged VLAN |
Y |
| Port-based VLAN |
Y |
| Virtual LAN features |
Tagged VLAN,Port-based VLAN |
| Certification |
| Certification |
FCC, CE, RoHS |
| Packaging content |
| Cables included |
AC |
| Rack mount kit |
Yes |
