| Networking |
| Maximum data transfer rate |
600 Mbit/s |
| Networking standards |
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3ac |
| Wi-Fi |
Yes |
| Wi-Fi band |
Dual-band (2.4 GHz / 5 GHz) |
| Frequency range |
2.4 - 5 GHz |
| Top Wi-Fi standard |
Wi-Fi 5 (802.11ac) |
| Wi-Fi standards |
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| WLAN data transfer rates supported |
11,54,150,433,600 Mbit/s |
| Modulation |
16-QAM, 64-QAM, 256-QAM, CCK, DBPSK, DQPSK, OFDM |
| Security algorithms |
64-bit WEP, 128-bit WEP, 802.1x RADIUS, WPA, WPA2, WPA2-AES, WPA2-PSK, WPA2-TKIP, WPS |
| System requirements |
| Windows operating systems supported |
Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows |
| Mac operating systems supported |
Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.7 Lion, Mac OS X 10.7.5 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks |
| Linux operating systems supported |
Yes |
| Weight & dimensions |
| Width |
41 mm |
| Depth |
19.5 mm |
| Height |
8.7 mm |
| Ports & interfaces |
| Connectivity technology |
Wireless |
| Host interface |
USB |
| Interface |
WLAN |
| USB version |
2.0 |
| Operational conditions |
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-40 - 70 °C |
| Operating relative humidity (H-H) |
10 - 90% |
| Storage relative humidity (H-H) |
5 - 90% |
| Design |
| Internal |
No |
| Component for |
PC/Laptop |
| Product colour |
Black |
| Antenna |
Yes |
| Antenna design |
Internal |
| Antenna direction type |
Omni-directional |
| Transmitting power (CE) |
20 dBm |
| Transmitting power (FCC) |
20 dBm |
| LED indicators |
Status |
| Operating modes |
Infrastructure mode |
| Logistics data |
| Harmonized System (HS) code |
85176990 |
| Packaging data |
| Package width |
138 mm |
| Package depth |
128 mm |
| Package height |
30 mm |
| Package weight |
90 g |
| Technical details |
| Compliance certificates |
CE, Federal Communications Commission (FCC), RoHS |
| Packaging content |
| Resource CD |
Yes |
| Quick installation guide |
Yes |
| Sustainability |
| Sustainability compliance |
Yes |
