| Weight & dimensions |
| Width |
70 mm |
| Depth |
77 mm |
| Height |
125 mm |
| Packaging data |
| Package type |
Box |
| Package width |
171 mm |
| Package depth |
104 mm |
| Package height |
99 mm |
| Package weight |
380 g |
| Networking |
| Cabling technology |
10/100Base-T(X) |
| Networking standards |
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Wi-Fi |
Yes |
| Wi-Fi standards |
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Wi-Fi data rate (max) |
867 Mbit/s |
| Wi-Fi band |
Dual-band (2.4 GHz / 5 GHz) |
| Security algorithms |
64-bit WEP, 128-bit WEP, WPA, WPA2-PSK |
| Operational conditions |
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-40 - 70 °C |
| Operating relative humidity (H-H) |
10 - 90% |
| Storage relative humidity (H-H) |
5 - 90% |
| Ports & interfaces |
| Ethernet LAN (RJ-45) ports |
1 |
| Power |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50/60 Hz |
| Power consumption (typical) |
8 W |
| Packaging content |
| Quick start guide |
Yes |
| Design |
| Product colour |
White |
| LED indicators |
Yes |
| On/off switch |
Yes |
| Reset button |
Yes |
| Antenna |
| Antennas quantity |
2 |
| Antenna type |
Internal |
| Transmitting power (CE) |
6.5 - 18 dBm |
| Transmitting power (FCC) |
8 - 19 dBm |
| Performance |
| Type |
Network repeater |
| Maximum transfer distance |
3048 m |
| Data transfer rate |
867 Mbit/s |
| Ethernet LAN data rates |
10,100 Mbit/s |
| WPS push button |
Yes |
| Windows operating systems supported |
Windows 10, Windows 2000, Windows 7, Windows 8, Windows 8.1, Windows 98SE, Windows NT, Windows Vista, Windows XP |
| Mac compatibility |
Yes |
| Mac operating systems supported |
Yes |
| Linux operating systems supported |
Yes |
| Browser supported |
Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0 |
| Certification |
| Compliance certificates |
CE, RoHS |
