| Ports & interfaces |
| Basic switching RJ-45 Ethernet ports quantity |
0 |
| Basic switching RJ-45 Ethernet ports type |
No |
| Installed SFP modules quantity |
0 |
| Installed SFP+ modules quantity |
0 |
| SFP+ module slots quantity |
16 |
| Console port |
RJ-45/Micro-USB |
| Power connector |
DC-in jack |
| Networking |
| Networking standards |
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ad, IEEE 802.3x |
| 10G support |
Yes |
| Port mirroring |
Yes |
| IP routing |
Yes |
| Flow control support |
Yes |
| Link aggregation |
Yes |
| Broadcast storm control |
Yes |
| Rate limiting |
Yes |
| Spanning tree protocol |
Yes |
| Head-of-line (HOL) blocking |
Yes |
| VLAN support |
Yes |
| Virtual LAN features |
Private VLAN, Protocol-based VLAN, Tagged VLAN, Voice VLAN |
| Number of VLANs |
4000 |
| Power |
| Power source |
AC |
| Power supply included |
Yes |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50/60 Hz |
| Power consumption (max) |
32.74 W |
| Operational conditions |
| Operating temperature (T-T) |
0 - 45 °C |
| Storage temperature (T-T) |
-40 - 70 °C |
| Operating relative humidity (H-H) |
10 - 90% |
| Storage relative humidity (H-H) |
5 - 90% |
| Heat dissipation |
111.71 BTU/h |
| Weight & dimensions |
| Width |
440 mm |
| Depth |
220 mm |
| Height |
44 mm |
| Security |
| DHCP features |
DHCP relay, DHCP server, DHCP snooping, DHCPv6 client, DHCPv6 snooping |
| Access Control List (ACL) |
Yes |
| IGMP snooping |
Yes |
| Security algorithms |
HTTPS, SSH, SSH-2, SSL/TLS |
| MAC address filtering |
Yes |
| Static port security |
Yes |
| SSH/SSL support |
Yes |
| Loop protection |
Yes |
| BPDU filtering/protection |
Yes |
| IP-MAC-Port binding |
Yes |
| Authentication |
Guest VLAN, MAC-based authentication, Port-based authentication, Web-based authentication |
| Authentication type |
AAA, TACACS+ |
| Queue scheduling algorithms |
SP, WRR+SP, Weighted Round Robin (WRR) |
| Packaging data |
| Package type |
Box |
| Data transmission |
| MAC address table |
32000 entries |
| Switching capacity |
320 Gbit/s |
| Forwarding rate |
238.08 Mpps |
| Number of queues |
8 |
| Static route |
Yes |
| Jumbo frames support |
Yes |
| Jumbo frames |
9000 |
| Packet buffer memory |
24 MB |
| Management features |
| Switch type |
Managed |
| Switch layer |
L2+/L3 |
| Quality of Service (QoS) support |
Yes |
| Web-based management |
Yes |
| Cloud-managed |
Yes |
| Traffic classification |
Yes |
| ARP inspection |
Yes |
| Configuring Location Settings (CLI) |
Yes |
| System event log |
Yes |
| MIB support |
RFC2925, RFC2618, RFC2620, RFC2021, RFC2819, RFC2674, RFC1493, RFC1643, RFC2233, RFC1213 |
| Protocols |
| Management protocols |
SNMPv1/v2c/v3, SNTP |
| IPv4 & IPv6 features |
IPv6 Telnet, IPv6 ping, IPv6 tracert |
| Power over Ethernet (PoE) |
| Power over Ethernet (PoE) |
No |
| Design |
| Rack mounting |
Yes |
| Product colour |
Black |
| LED indicators |
Yes |
| Multicast features |
| Multicast support |
Yes |
| Multicast Listener Discovery (MLD) snooping |
Y |
| Certification |
| Certification |
CE, FCC, RoHS |
| Packaging content |
| Cables included |
AC |
| Quick start guide |
Yes |
| Manual |
Yes |
| Rack mount kit |
Yes |
