| System requirements |
| Windows operating systems supported |
Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 x64, Windows 2000, Wind |
| Mac operating systems supported |
Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur, Mac |
| Linux operating systems supported |
Yes |
| Server operating systems supported |
Windows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016 |
| Other operating systems supported |
Windows XP Embedded |
| Operational conditions |
| Operating temperature (T-T) |
0 - 55 °C |
| Storage temperature (T-T) |
-20 - 85 °C |
| Operating relative humidity (H-H) |
5 - 95% |
| Power |
| Input voltage |
5 V |
| Input current |
0.25 A |
| Power plug type |
Type M |
| USB powered |
Yes |
| Weight & dimensions |
| Width |
100 mm |
| Depth |
180 mm |
| Height |
43.2 mm |
| Weight |
544 g |
| Ports & interfaces |
| Ports quantity |
8 |
| Host interface |
USB 2.0 Type-B |
| Hub interfaces |
Serial |
| RS-232 ports |
8 |
| Card reader integrated |
No |
| Other features |
| Chipset |
FTDI - FT232RL |
| Packaging content |
| Cables included |
USB |
| Manual |
Yes |
| DIN rail kit included |
Yes |
| Drivers included |
Yes |
| Performance |
| Data bits |
7, 8 |
| Stop bits |
1, 2 |
| Parity bit |
Even, Mark, No, Odd, Space |
| FIFO (First In, First Out) |
4048 B |
| Baud rate |
921.6 Kbit/s |
| Mean time between failures (MTBF) |
146300 h |
| Technical details |
| Compliance certificates |
CE, RoHS |
| Logistics data |
| Master (outer) case width |
405 mm |
| Master (outer) case length |
510 mm |
| Master (outer) case height |
320 mm |
| Products per master (outer) case |
14 pc(s) |
| Harmonized System (HS) code |
84719000 |
| Packaging data |
| Package width |
296 mm |
| Package depth |
191 mm |
| Package height |
71 mm |
| Package weight |
862 g |
| Features |
| Product colour |
Black |
| Housing material |
Steel |
| LED indicators |
Activity |
| Sustainability |
| Sustainability compliance |
Yes |
